ZK-SC800-12-W-B
ZK-SC800-12-W-B
- Access and time & attendance control IP65 IK04
- EM/MF card and PIN
- 50.000 cards | 200.000 records
- 2.4" TFT | TCP/IP, WiFi, RS485 and Wiegand
- Soft. Attendance: ZKBioTime 8 and GoTime Cloud
- Soft. Access: ZKBioCV
A stand-alone access control device consists of a combination of a controller and a reader in a single unit: is able to identify users, decide whether or not they have permission to access the installation and operate the electronic lock through its relay. Hybrid terminals combine access control and time and attendance control, being able to perform time and attendance control of workers at the moment they identify themselves.
This equipment allows identification through cards or key fobs with RFID EM technology of 125 kHz and MF of 13.56 MHz, as well as keypad for numeric codes.
Its 2.4" screen facilitates the operation and configuration of the equipment locally, both to use it autonomously without software, and to set some parameters required to connect to the software, such as network configuration.
Its exterior grade IP65 allows it to be installed outdoors. In addition, its IK04 anti-vandalism rating allows it to withstand the most challenging environments.
The ZKBioCV Security software is used to configure users, schedules and access groups, as well as special functions, relay opening times or reader reading times.
- ZKTeco
- Stand-alone access control and time & attendance reader
- Identification by EM card and MF, password and/or combinations
- Display 2.4" TFT color display
- Capacity 50.000 cards/passwords and 200.000 records
- TCP/IP and WiFi communication
- Integrated controller (door sensor, push button and relay)
- Suitable for exterior IP65
- Anti-vandal IK04
- Compatible with ZKBioCV access software, free of charge up to 5 doors (purchase perpetual license)
- Compatible with free ZKBioTime8, presence software up to 2 devices and 100 users (purchase perpetual license)
- Compatible with GoTime Cloud presence software (purchase annual license)
- Any license can be found in the Software category of the website
- EasyAccess range
Specifications
| Brand | ZKTeco |
| Model | ACO-SC800-12-W-B |
| CPU | 1GHz Dual Core CPU, DDR2 64M, Flash 256M |
| Capacity | Up to 50.000 cards/passwords |
| Records | 200.000 registers |
| Identification modes | Card, PIN and/or combinations |
| Proximity card | RFID EM 125 kHz and MF 13.56 MHz |
| Screen | 2.4" Color TFT |
| Communication | TCP/IP, WiFi, RS485 and Wiegand |
| Integrated controller | Door sensor, push button, relay, Wiegand IN/OUT, alarm input and alarm output |
| Software | Access Software: ZKBioCVSecurity Time and Attendance Software: ZKBioTime 8.0 | GoTime Cloud |
| Power | DC 12 V / 3 A max. |
| Degree of protection | Outdoor IP65 Anti-vandal IK04 |
| Temp. operation | -10 ºC ~ +55 ºC |
| Dimensions | 85 (W) x 143 (H) x 20 (D) mm |
| Weight | 600 g |
In the box
- ZKTeco stand-alone device
- Mounting material
- User instructions
