ZK-FR1500A-WP-EM
- Access reader
- Silk ID fingerprint and EM card access
- LED and acoustic indicator
- RS485
- Compatible with ZK-ATLAS-x60
- Suitable for outdoor use IP65 | Recessed
An access reader is used to identify users who want to access a system protected by an access controller. Transmits the credential information, with the controller deciding how to proceed.
This reader allows identification through cards or key fobs with 125 kHz RFID EM technology, as well as fingerprint biometrics.
The connection to the controllers is made through RS485. This protocol allows a secure connection in the outdoor installation with its IP65 grade.
- ZKTeco
- Access reader for controller
- Fingerprint and EM card access
- SilkID Optical Sensor
- LED indicator
- RS485 Communication
- Flush mountable
- Suitable for exterior IP65
- Compatible with ZK-ATLAS-x60 controllers
Specifications
| Brand | ZKTeco |
| Model | ACC-ATLAS-FR1500A-WP-1 |
| Sensor | ZKSilkID Optical Sensor |
| Sensor resolution | 500DPI |
| Activation sensor | Infrared auto-activation |
| Algorithm | ZK Finger 10.0 |
| Read time | < 1 sec |
| Card reading distance | Up to 10 cm |
| Read time | < 300ms |
| Identification modes | Fingerprint and card (RFID EM 125 kHz) |
| Outputs | RS485 |
| Compatibility | ZKTeco ZK-ATLAS x60 controllers |
| Power | DC 12 V / 140 mA máx. |
| Degree of protection | Suitable for exterior IP65 |
| Temp. operation | -10 ºC ~ +45 ºC |
| Dimensions | 77.3 (W) x 121 (H) x 38 (D) mm |
| Weight | 160 g |
In the box
- ZKTeco Biometric access reader
- Mounting material
