XS-XVR6216A-WIZ

XS-XVR6216A-WIZ

Log in voor B2B prijs
  • DVR 5n1 X-Security
  • 16 CH HDTVI/HDCVI/AHD/CVBS + 8 IP
  • Maximum resolution 5 Mpx
  • Audio over coaxial | SMD | AcuPick | AcuPick
  • 2 CH facial recognition
  • IVS Wizsense | 2 HDD | Alarms
  • X-Security
  • XVR 5n1
  • 16 HDTVI/HDCVI/AHD/CVBS video CH
  • 8+16 IP channels
  • 16 CH coax audio
  • 1 input / 1 audio output
  • H.265+/H.265/H.264+/H.264
  • Maximum resolution 5 Mpx
  • PTZ Control (RS485/Coaxial)
  • Outputs 4K HDMI & VGA
  • 128 Mbps bandwidth supported
  • SMD Plus: Advanced human- and vehicle-based motion detection (Up to 16 CH by the NVR itself)
  • IVS WizSense: classification of human and vehicle (up to 4 CH by the NVR itself)
  • Facial recognition (Up to 2 CH by the NVR itself)
  • AcuPick: Intelligent search for a specific target based on human and vehicle from AI events with high accuracy
  • Video quality analysis with AI
  • Alarms
  • Mouse
  • 2 USB Ports
  • Space for 2 HDD
  • ONVIF Compatible

Specifications

Brand X-Security
Video format HDTVI / HDCVI / AHD / CVBS / IP
Video inputs 16 Channels BNC (HDTVI / HDCVI / AHD / CVBS)
Hybrid configuration Up to 24 IP (6 Mpx channels), replacing all BNC channels
Video / audio compression H.265+/H.265/H.264+/H.264
Video input resolution CVI: 5 MP at 25 fps; 5 MP at 20 fps; 5 MP@10/12.5 4 fps; 25/30 MP at 1080p fps; 25/30 at 720p fps; 50/60 to 720p fps; 25/30 to [%VAR%] fps.
TVI: 5 MP (2560 × 1944) at 20 fps; 5 MP (2960 × 1665) at 20/25 fps; 4 MP at 25/30 fps; 1080p at 25/30 fps; 720p at 25/30 fps.
AHD: 5 MP at 20 fps; 4 MP at 25/30 fps; 1080p at 25/30 fps; 720p at 25/30 fps.
Video outputs 1 HDMI 4K, 1 VGA
Display resolution HDMI: 4K (3840x2160), 1920×1080, 1280×1024, 1280×720
VGA: 1920×1080, 1280×1024, 1280×720

Resolution changes to 1920x1080, 1280x1024, 1280x720 when face recognition, IVS, is active. SMD or Acupick
Total bandwidth 128 Mbps
Coding Coding enhancement disabled:
Main flow:
Channels 1-4 5M-N@(1 fps–25 fps), other 5M-N@(1fps–12 fps);
Channels 1-4 4M-N/1080p@(1 fps–30 fps), other 4MN/1080p@(1 fps–15 fps); 1080N/720p/960H/D1/CIF@(1 fps–30 fps);
Secondary flow: D1/CIF@(1 fps–15 fps);

Coding enhancement enabled:
Main flow:
Channels 1-8 5M-N@(1 fps–20 fps), other 5M-N@(1 fps-12 fps); (4 channels can be transformed to 5MP@6 fps)
Channels 1-8 4M-N/1080p@(1 fps–25 fps), other 4MN/1080p@(1 fps–15 fps); 1080N/720p/960H/D1/CIF@(1 fps–30 fps);
Secondary flow: D1/CIF@(1 fps–15 fps);

*When encryption enhancement is enabled, video quality analysis, scene change, face recognition, face detection, IVS perimeter protection and AcuPick cannot be used.
Video bitrate 32 kbps–6144 kbps
Simultaneous multifunction Pentaplex: Live, Recording, Playback, Backup and Remote Access
Audio inputs 16 BNC (coaxial audio)
1 Channel RCA
Audio outputs 1 Channel RCA
Bidirectional audio Reusing the audio input/output
Audio Compression G.711a; G.711u; PCM
Audio bitrate 64 kbps
Alarms 16 inputs / 3 outputs
SMD (Advanced Motion Detection) Advanced motion detection based on human- and vehicle-induced pixel shift reducing false alarms
By NVR: Up to 16 CH
Per IP camera with SMD: All channels (Up to 32 targets/second)
IVS Perimeter Protection Intelligent algorithm based on human and vehicle detection with high accuracy filtering out any objects of no interest in the environment such as rain, leaves, bright lights, etc.
IVS is based on line crossing, area intrusion, region of entry, ...
By NVR: Up to 4 CH (Up to 10 IVS rules)
AcuPick Fast target search up to 2 CH of humans and vehicles over live video or IVS Perimeter Protection event-based recording
Face detection 6 facial attributes.
Up to 2 channels (up to 12 facial images per second on each channel)
Facial recognition Storage in up to 10 databases with 10.000 images.
Up to 2 analog channels for live face comparison
Video quality analysis using AI 16 channels: supports detection of brightness levels, color casts, blur, overexposure, contrast levels, and black & white.
Change of scene 1 channel
Irregular masking of black blocks 1 channel
Recording method Manual, programmed, motion detection, alarm
Backup USB / Network
Internal memory 2 SATA HDD 3.5" of up to 16 TB (not included)
Communication RS485 (PTZ)
1 x USB 2.0 (front), 1 x USB 3.0 (back)
RJ45 10/100/1000 (Ethernet)
Remote access Web browser (ActiveX), mobile phone application or PSS software
Operating temperature –10 °C ~+55 °C
Power DC 12V / 4 A / <12 W (sin HDD)
Dimensiones 53 (Al) x 375 (An) x 289.6 (Fo) mm
Peso 1.8 kg

In the box

  • Grabador 5 en 1 X-Security
  • Ratón
  • Alimentador 12VDC
