XS-XVR6104T-WIZ
Ga direct naar de productinformatie
XS-XVR6104T-WIZ
- DVR 5n1 X-Security
- 4 analog channels ((5 Mpx) / 4+2 IP channels ((6 Mpx)
- Audio over coaxial
- HDMI | VGA | Space for 1 HDD
- AcuPick | Facial Recognition | SMD Plus
- WizSense | Perimeter Security
- X-Security
- DVR 5n1
- 4 HDTVI/HDCVI/AHD/CVBS video channels up to 5 Mpx / 4+2 IP channels up to 6 Mpx / 1 two-way audio channels
- H.265+/H.265/H.264+/H.264
- Resolution 8Mpx, 6Mpx, 5Mpx, 4Mpx, 3Mpx,1080p, 720p
- PTZ Control (RS485/Coaxial)
- Two-way audio over coaxial cable
- HDMI Full HD, VGA & CVBS Outputs
- WizSense
- 2 CH AcuPick
- 4 CH Perimeter Protection
- 2 CH Facial Recognition and Detection
- Smart Motion Detection
- Human and Vehicle Detection (Available for 4 coaxial video channels and 6 IP channels)
- 4 CH AI Video Quality Analytics
- 1 CH Scene change
- Mouse
- 2 USB Ports
- HDMI
- VGA
- Space for 1 HDD up to 16 TB
Specifications
| Brand | X-Security |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 4 Channels BNC (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | Up to 6 IP (6 Mpx channels), replacing all BNC channels |
| Video outputs | 1 HDMI 1080p, 1 VGA |
| Video compression | H.265+ / H.265 / H.264+ / H.264 |
| Dual-Stream | Yes |
| Video Bit Rate | 32 kbps–6144 kbps |
| Display resolution | HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Total bandwidth | 32 Mbps |
| Recording resolution | 6 MP; 5 MP@25 fps; 5 MP@20 fps; 5 MP@10/12.5 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@50/60 fps; 720p@25/30fps |
| Main Stream coding | Encoding enhancement disabled: Channels 1-2 5M-N@(1 fps–25 fps), other 5M-N@(1fps–12 fps); Channels 1-2 4M-N/1080p@(1 fps–30 fps), others 4M-N/1080p@(1 fps–15 fps); 1080N/720p/960H/D1/CIF@(1 fps–30 fps) Coding enhancement enabled: 4-ch 5M-N@(1 fps-25 fps);(4 channels can be converted to 5MP@6 fps) 4-ch 4M-N/1080p@(1 fps–25 fps); 1080N/720p/960H/D1/CIF@(1 fps–30 fps); *When encoding enhancement is enabled, Video Quality Analytics, Scene Change, Face Recognition, Face Detection, Perimeter Protection, and AcuPick cannot be used. |
| Extra Stream coding | Encoding enhancement disabled: D1/CIF@(1 fps–15 fps) Coding enhancement enabled: D1/CIF@(1 fps–15 fps); Sub stream: D1/CIF@(1 fps–15 fps); *When encoding enhancement is enabled, Video Quality Analytics, Scene Change, Face Recognition, Face Detection, Perimeter Protection, and AcuPick cannot be used. |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Bidirectional audio | Coaxial: 4 BNC channels Reusing the audio input/output |
| Audio inputs | 1 channel RCA 4 canales BNC (Audio Coaxial) |
| Audio outputs | 1 channel RCA |
| Audio Compression | G.711a; G.711u; PCM |
| Video Bit Rate | 32 kbps–6144 kbps |
| Audio Bit Rate | 64 kbps |
| Alarms IN/OUT | Does not have |
| AcuPick | Up to 2 channels |
| Facial Detection | 2 channels (up to 8 facial images per channel) 6 attributes |
| Perimeter Protection | Up to 4 analog channels that support Tripwire and AI-powered intrusion detection |
| Video analysis | IVS: Face detection / People and vehicle recognition / Line crossing / Intrusion |
| Facial recognition | Up to 2 analog channels for live face comparison Up to 10 facial databases with 20000 images |
| Intelligent motion detection | Up to 4 analog channels capable of distinguishing between humans and vehicles (SMD Plus) or 6 channels (SMD) |
| AI Video Quality Analytics | 4 Channels |
| Change of scene | 1 Channel |
| Recording method | Manual, programmed, motion detection, alarm |
| Backup | USB / Network |
| Internal memory | 1 SATA HDD 3.5" of up to 16 TB (not included) |
| Communication | RS485 (PTZ) /2 x USB (Mouse and backup) / RJ45 10/100 (Ethernet) |
| Remote access | Web browser (ActiveX), mobile phone application or PSS software |
| Power | DC 12V / 1.5A |
| Operating temperature | –10 ~ +55 °C |
| Dimensions / Weight | 47.6 (H) x 260 (W) x 237.8 (D) mm / 0.84 Kg |
In the box
- DVR 5 in 1 X-Security
- Mouse
