XS-T744SWA-2P-0280
Ga direct naar de productinformatie
XS-T744SWA-2P-0280
- X-Security Turret Camera PRO Range
- Output 4in1
- 1/2.8" CMOS
- 2.8 mm Lens | 30 m IR range
- Audio over Coaxial cable in HDCVI
- Weatherproof IP67
- X-Security
- Turret HDTVI, HDCVI, AHD and Analog Camera
- PRO Range
- 1/2.8" CMOS
- 2 Mpx (1920x1080)
- Output 4in1
- 2.8 mm Lens
- 0 Lux
- IR Range 30 m
- Audio over Coaxial
- Starlight
- IR Cut
- Weatherproof IP67
Specifications
| Brand | X-Security |
| Range | PRO |
| Image sensor | 1/2.7" CMOS |
| Maximum resolution | 2 Mpx (1920x1080) |
| Resolution | 1080p (1920 × 1080); 960H (960 × 576/960 × 480) |
| Lens | 2.8 mm |
| Minimum illumination | 0.002 Lux/F1.6, 30 IRE, 0 Lux IR on |
| Infrared lighting | 0 Lux / SMART IR (30 m) |
| Day / Night | Auto / Colour / BW (Black and White) |
| Audio | Built-in microphone (Audio via coaxial cable in HDCVI) |
| Video output | 1 x BNC switchable between HDTVI / HDCVI / AHD / CVBS |
| Video output switching | Via Switch |
| Basic functions | OSD menu (remote) |
| Configurable OSD functions | DWDR, 3D-DNR, HLC, BLC, Mirror, Smart IR |
| Lens Adjustment | 3 Axis |
| Power | DC 12 V / 434 mA, 3.1 W max |
| Degree of protection | Weatherproof IP67 |
| Temp. operation | -40º C ~ +60º C |
| Material | Metallic |
| Dimensions | 88.1 (H) x 109.9 (Ø) mm |
| Weight | 450 g |
In the box
- X-Security Turret Camera 4N1
- 3 plugs and 3 screws for mounting
- User instructions
- Allen wrench
- Installation template
