XS-SWI0402HIPOE-MGF-120-DIN
Ga direct naar de productinformatie
XS-SWI0402HIPOE-MGF-120-DIN
- X-Security PoE Switch DIN Rail
- 2 PoE RJ45 + 2 SFP ports
- Speed 10/100/1000Mbps
- 90W ports 1-2 / 120W Maximum total power
- PoE / PoE+ / Hi-PoE / Up to 250m / PoE Watchdog
- VLAN/STP/RSTP/ERPS/LACP/StaticLAG/IGMP Snooping
- X-Security
- Industrial Managable Switch
- 2 PoE ports RJ45 Gigabit + 2 SFP Gigabit ports
- Up to 90W on ports 1-2
- Supports PoE power supply up up 120W in total for all ports
- PoE Extended up to 250 meters
- PoE Watchdog
- Compatible with PoE IEEE802.3af/at , Hi-PoE and IEEE 802.3bt
- DIN rail mount
Specifications
| Interface | 2 PoE ports RJ45 + 2 fiber SFP ports + 1 Console Port |
| Port speed | 2x 10/100/1000Mbps + 2 x 1000Mbps Base-X |
| Power supply | Up to 90W on 1-2 (120 W ports for the whole device) |
| PoE features | According to standard: IEEE 802.3af PoE / IEEE 802.3at PoE+ / IEEE802.3bt Hi-PoE Up to 120W of Total PoE Power PoE Watchdog, the switch automatically detects if the PoE-powered device is not operational. PoE Extended Up to 250m to 10Mbps |
| VLAN | 4K 10 VLAN Interface |
| DHCP | Customer Server DHCP Snooping |
| Security Functions | IEEE 802.1X ACL |
| Redundancy | STP RSTP ERPS |
| Management Protocols | Web CLI Telnet SNMP V1/V2/V3 |
| Power | DC 48~57VDC (power supply not included) Redundant source: Two power supplies can be connected to the device |
| Installation | DIN rail, desktop |
| Maximum Consumption | 120W |
| Operating temperature | -40º C ~ 75º C |
| Dimensions | 94,4 x 53,5 x 135 mm |
| Weight | 0,85Kg |
| Installation | Tabletop and DIN Rail |
In the box
- X-Security PoE Switch
- User instructions
- DIN Rail Mounting Kit
