XS-IPD850A-4U-MIND
Ga direct naar de productinformatie
XS-IPD850A-4U-MIND
- X-Security Dual Dome IP Camera
- 2x 4 Megapixel (2560x1440)
- 2.8mm fixed lens
- WDR 120dB | Dual Light(IR 60m and White Light 60m)
- WizSense, with human and vehicle classification
- MicroSD 256GB / IP67 & IK10
- X-Security
- Dual Lens IP Dome Camera
- PRO Range
- 1/2.7" Progressive CMOS
- 2x 4 Megapixel (2560x1440)
- 2.8mm lens
- 0.006 Lux
- IR30m
- Compression H.265+/H.265/H.264+/H.264
- RJ-45 10/100 BaseT
- SMD 3.0
- IVS WizSense: classification of human and vehicle
- Intelligent search
- People count
- Built-in microphone
- WDR 120dB
- IR Cut
- MicroSD up to 256GB
- PoE IEEE802.3af
- Weatherproof IP67
- ONVIF Compatible
Specifications
| Brand | X-SECURITY |
| Image sensor | 2x 1/2.7” CMOS image sensor |
| Maximum resolution | 2x 4 Megapixel (2560 × 1440) |
| Lens | 2.8 mm (H: 95°; V: 52°; D: 114°) |
| Resolution | 4MP (2560 × 1440) / 3MP (2304 × 1296) / 1080p (1920× 1080) / 1.3MP (1280 × 960) / 1.3MP (1280 × 960) / 720p (1280 × 720) / D1 / CIF |
| Main Stream rate | 2560 × 1440 @(1–25/30 fps ) |
| Extra Stream rate | 704 × 576 / 704 × 480@(1–30 fps) |
| Rate Third stream | 1920 × 1080 @ (1–25/30 fps) |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| Minimum illumination | 0.005 lux@F1.6 (Colour, 30 IRE) 0.0005 lux@F1.6 (B/W, 30 IRE) 0 lux (Illuminator on) |
| IR Range | 30m |
| Range performance | 63.6 (D), 25.4 (O), 12.7 (R), 6.4 (I) |
| Video bit rate | H.264: 32 kbps–6144 kbps H.265: 12 kbps–6144 kbps |
| SSA (Scene Self-Adaptation) | Yes |
| Image improvements | WDR (120 dB), BLC, HLC, AWB, AGC, 3D-NR, ROI , Smart IR |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support the accurate classification and detection of vehicles and persons) |
| People count | Yes |
| Network interface | Ethernet 10/100m BaseT |
| Audio | 1 Input / 1 Output / Built-in Microphone |
| Audio Compression | G.711a; G.711Mu; G.726; PCM |
| External storage | 256 GB microSD card slot |
| Alarms | 2 Inputs / 2 Outputs |
| Remote access | WEB, CMS (DSS/PSS), Smartphone and NVR interface |
| Interoperability | ONVIF (Profile S/Profile G); .CGI; P2P |
| Power | DC 12 V / 3.1 W, PoE IEEE802.3af |
| Temp. operation | -40º C ~ +60º C |
| Material | Metallic |
| Lens Adjustment | 3 Axis Bread: 0°–175° Tilt: 0°–65° Rotation: 0°–360° |
| Color | White |
| Degree of protection | Waterproof IP67, Anti-vandal IK10 |
| Dimensions | 66.2 mm (D) x 122 (Ø) mm |
| Weight | 520 g |
In the box
- X-Security IP camera
- Installation material
- User instructions
- CD with software and instructions
