XS-IPB829ZA-8P-DL-WIZ-BLACK
Ga direct naar de productinformatie
XS-IPB829ZA-8P-DL-WIZ-BLACK
- X-Security IP Bullet Camera
- 8 Megapixel (3840x2160)
- 2.7~13.5 mm Motorised Lens
- WDR 120dB | Dual Light (IR 60m and White Light 60m)
- WizSense, with human and vehicle classification
- MicroSD | IP67 | PoE | SMD Plus
- X-Security
- IP Bullet Camera with Dual Light
- PRO Range
- 1/2.7" Progressive CMOS
- 8 Megapixel (3840x2160)
- 2.7~13.5mm motorised lens
- 0.008 Lux
- Dual light: IR + white led
- Dual light range: 60 m
- Compression H.265; H.264; H.264H; H.264B; MJPEG
- RJ-45 10/100 BaseT
- SMD Plus Smart Search
- IVS WizSense: classification of human and vehicle
- Built-in microphone
- Audio
- Alarms
- WDR 120 dB
- IR Cut
- MicroSD card slot up to 256 GB
- PoE (IEEE802.3af)
- Weatherproof IP67
- ONVIF Compatible
- Black colour
Specifications
| Brand | X-SECURITY |
| Maximum resolution | 8 Megapixel (3840x2160) |
| Image sensor | 1/2.8” Progressive CMOS |
| Lens | Motorised 2.7~13.5 mm |
| Viewing angle | H: 114°~32°; V: 58°~17°; D: 138°~36° |
| Range performance | 85.3~280 m (D), 34.1~112 m (O), 17.1~56 m (R), 8.5~28 m (I) |
| Main Stream rate | 3840x2160@(1–20 fps) / 2688x1520@(1-25/30 fps) |
| Extra Stream rate | 704 × 576@(1–25 fps) / 704 × 480@(1–30 fps) |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| Minimum illumination | 0.008 lux@F1.0 (Colour, 30 IRE) 0.0008 lux@F1.0 (B/W, 30 IRE) 0 lux (with illuminator on) |
| Dual Light | Detection modes: Intelligent Mode (By default, IR activated and switches to white LED in the presence of a target) IR mode White LED mode |
| IR range | 60 m (IR) 60 m (White light) |
| Image improvements | WDR 120 dB, BLC, HLC, AWB, AGC, 3D-NR, ROI , Smart IR |
| SMD Plus | Yes (Human and vehicle based motion detection) |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support the accurate classification and detection of vehicles and persons) |
| Intelligent search | Using microSD card or NVR X-Security |
| Network interface | Ethernet 10/100M BaseT |
| Audio | 1 Input / 1 Output Built-in microphone |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Alarms | 1 Input / 1 Output |
| Remote access | WEB, CMS (Smart PSS Lite / DSS / DMSS), Smartphone and NVR interface |
| Material | Metallic |
| Interoperability | ONVIF (Profile S/Profile T); CGI |
| Power | DC 12 V / 3W PoE IEEE802.3af |
| Temp. operation | -40º C ~ +60º C |
| Degree of protection | Weatherproof IP67 |
| Dimensions | 238.5 (D) x 90.7 (W) x 90.7(Al) mm |
| Weight | 760 g |
| Color | Black |
In the box
- X-Security IP camera
- Installation material
- User instructions
- CD with software and instructions
