UV-XVR-116G3
Ga direct naar de productinformatie
UV-XVR-116G3
- Video recorder 5n1
- Uniarch
- 16 CH HDTVI / HDCVI / AHD / CVBS + 8 extra IP
- Audio
- Supports 1 hard disk
- Uniarch
- DVR 5n1
- 16 BNC video CH (IP-replaceable)
- AHD, TVI, CVI, CVBS, CVBS
- 40 Mbps bandwidth supported
- Maximum IP resolution 8 Mpx
- Maximum analog resolution 5 Mpx
- Audio
- HDMI and VGA output
- RS485
- 2 x USB 2.0
- Mouse
- Space for 1 HDD up to 6 TB
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
Specifications
| Brand | Uniarch |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 16CH BNC |
| Hybrid configuration | Up to 16 IP Channels (8Mpx) replacing all the BNC channels |
| Video outputs | 1 HDMI Full HD, 1 VGA |
| Audio inputs | 1 Channel RCA |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input/output |
| Display resolution | 1920x1080, 1600x1200, 1280x1024, 1280x720, 1024x768 |
| Maximum IP recording resolution | 8 Mpx |
| Analog cameras supported | TVI / AHD: 5MP@12FPS; 4MP@15FPS; 1080P@30FPS CVI: 1080P@30FPS; 720@30FPS |
| Main Stream recording encoding | TVI/CVI/AHD 5MPLite@6FPS; 4MPLite@8fps; 1080PLite@15FPS; 720P@15FPS |
| Extra Stream recording encoding | D1@6FPS; D1@8FPS; D1@10FPS |
| Recording method | Manual, programmed, motion detection |
| Internal memory | 1 HDD SATA 3.5" of up to 6TB (not included) |
| External interface | 2 x USB (Mouse and backup) / RJ45 10M/100M/1000M (Ethernet) / RS485 |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Power | DC 12V / 10W |
| Dimensions / Weight | 260mm × 229mm × 47mm / 1.1 kg |
In the box
- 5 in 1 Uniview recorder
- Mouse
- Power adapter
