UV-FTP6A-300-BC23AWG-DCA-R-O
- Uniview FTP cable category 6A
- Driver OFC,100% copper
- Diameter 23 AWG-0,57mm
- CPR Dca Certificate
- Outer jacket LSZH / Color orange
- Supplied in wooden reels of 305 meters
- Uniview
- Bobbin of cable
- Length 305 m
- FTP
- Category 6A
- Driver OFC,100% copper
- Diameter 23 AWG-0,55mm
- FPE insulation
- LSZH jacket
- Insulation resistance ≤95Ω/km
- CPR Certificate
- Fire protection class: DCA
- Supplied in wooden spools
- Orange color
Specifications
| Brand | Uniview |
| Shielding | FTP |
| Category | Category 6A |
| Length | 305 meters |
| Conductor | Material: OFC, Pure copper Diameter: 23AWG 0.55±0.005 mm DC resistance: ≤95Ω/km |
| Isolation | Material: FPE Thickness: 0.38+0.03mm Diameter: 1.30±0.5 mm Colour: Blue/White-Blue, Orange/White-Orange, Green/White-Green,Brown/White-Brown |
| Cover | Material: LSZH Diameter: 7.6±0.3 mm Thickness: 0.55±0.15 mm Tensile strength: >10 Mpa Colour: Orange |
| Tear thread | Yes |
| Installation | Indoor |
| CPR Certificate | Cca |
| Room temp. | -20℃～75℃ |
| Packaging | Wooden spool |
| Packing dimensions | 400 x 200 x 240mm |
In the box
- 6A of 305m FTP Cat cable reel
