STK-HD140
- IP waterproof touchscreen monitor 66
- Supports 4 cameras with M12 connector
- 5 wired alarm inputs
- Adjustable digital parking lines
- Integrated speaker
- Voltage range 10 ~32V
Waterproof touchscreen monitor with IP66 protection. Supports 4 wired AHD channels with M12 connector. Has 5 alarm inputs for full screen display of the camera that generates the trigger (reverse gear or buttons on the driver's dashboard). Digital parking guidance lines are menu-driven and adjustable. Integrated speaker and input voltage range between 10 ~32V compatible with different types of vehicles
- IP waterproof touchscreen monitor 66
- Supports 4 cameras with M12 connector
- 5 wired alarm inputs
- Adjustable digital parking lines
- Integrated speaker
- Voltage range 10 ~32V
Specifications
| Protection | IP66 |
| Screen | capacitive touch 7 inches, menu icons and some gestures |
| Supported formats | 1080P30/1080P25/720P30/720P25/PAL/NTSC, quadrant view |
| Video channels | 4 analog cameras with connector M12 |
| Alarm inputs | 5 alarm inputs |
| Parking | Configurable parking guidance lines |
| Brightness | Adjustable to 3 ambient light levels 600 cd/m² |
| Resolution | 1024x3(RGB)x600 |
| Contrast | 700:1 |
| Viewing Angle | U: 85°/ D: 85°, R/L: 85° |
| Aspect ratio | 16:9 |
| Working temperature | -20~+70℃ |
| Storing temperature | -30~+80℃ |
| Consumption | 25W |
| Power supply for cameras | Max. 4×600mA, 12V |
| Power supply range | 10V-32V |
| Touch screen sensitivity | ≥ 80% |
| Working pressure | 10~110g |
| Display response time | <10ms |
In the box
- Pantalla
- Soporte
- Tornillos
- Visera
- Folleto con codigo QR
- Mando a distancia
