SF-SLEEPRADAR
- Safire® ancillary care radar sensor
- Heart rate and respiratory rate measurement
- Horizontal and vertical detection: -60° ~ 60º
- Wi-Fi communication
- Easy Plug&Play connection / Aerosense Care APP
- Alerts and reports
- Safire
- Auxiliary care radar sensor
- Human body sensing, body movement, respiration and heart rate monitoring
- Contactless measurement
- Periodic reports
- Up to 1.5 meters detection
- FMCW
- Frequency of 60 GHz
- Wi-Fi
- AerosenseCare App
- Easy to use, Plug&Play
- Power 5VVDC
Specifications
| Brand | Safire |
| General Function | Human body sensing, body movement detection, respiration and heart rate monitoring. |
| Alerts | Excessive sleep, frequent nocturnal activity, nocturnal wandering, absence of vital signs and abnormal sleep |
| Number of patients | 1 |
| Work Frequency | From 60 GHz |
| Modulation waveform | FMCW |
| Detection Angle | -60°~60º (H) / -60°~60º (V) |
| Detection Distance | 1.5m |
| Network Interface | Wi-Fi |
| Communication protocol | API and SDK |
| Remote access | Aerosense Care smartphone APP |
| Power | DC 5 V, 1 A, máx.5W, Type-C |
| Dimensions / Weight | Ø83 mm × 59 mm / 80 g |
| Temp. operation | -10 °C to 50 °C |
| Material | PC |
In the box
- Auxiliary care radar sensor
