SF-IPT020A-8I1-NIGHTPRO
Ga direct naar de productinformatie
SF-IPT020A-8I1-NIGHTPRO
- Safire Smart
- Turret IP camera range I1
- Resolution 8 Megapixel (3840x2160)
- Lens 2.8 mm | microphone | white light 20~30m
- TrueSense: Human and vehicle detection
- IP67 Rating | PoE (IEEE802.3af)
- Safire Smart
- I1
- Turret IP Camera
- 1/2.8" Progressive Scan CMOS
- 8 Megapixel (3840x2160)
- 2.8 mm Lens
- Minimum illumination 0.0005 Lux @F1.0, AGC ON | 0 Lux with Illumination
- White light range 20~30 m
- Compression H.265+ / H.264+
- WDR
- 3DNR
- Integrated microphone
- Audio
- TrueSense: Classification of human and vehicle
- Face detection
- Target count per line/area
- Heat map
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
- PoE (IEEE802.3af)
- Weatherproof IP67
Specifications
| Brand | Safire Smart |
| Range | I1 |
| Image sensor | 1/2.8" Progressive Scan CMOS |
| Maximum resolution | 8 Megapixel (3840x2160) |
| Minimum illumination | 0.0005 Lux @F1.0, AGC ON, 0 Lux with Illumination |
| White Light Scope | 20~30 m |
| Day/Night | Removable mechanical ICR filter |
| Electronic Shutter | 1/2~1/100.000 s |
| Main Stream rate | 8MP/6MP/4MP/2K/1080P( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps ) |
| Extra Stream rate | 1080P(1~15fps)/720P/D1/640 ×360 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps ) |
| Third Stream Rate | 720P/D1/640 ×360/VGA/CIF/480×240 ( 60Hz : 1 ~ 30fps; 50Hz: 1~25fps ) |
| Compression | H.265+ / H.265 / H.264+ / H.264 |
| Bitrate | 64 Kbps ~ 12 Mbps |
| Lens | 2.8 mm |
| Viewing Angle (FOV) | H: 110°, V: 59°, D: 129° |
| Range performance | 76 m (D), 30 m (O), 15 m (R), 7 m (I) |
| Image improvements | WDR, BLC, HLC, 3D-DNR, AWB, ROI, Mirror Function, Privacy Mask, ROI |
| Motion Detection | Yes |
| Smart Features | Advanced artificial intelligence based on human, vehicle and two-wheeled vehicle classification on: Area Intrusion, Line Crossing, Entry Region, Exit Region Other smart events: dropped object, removed object, Video exceptions (change of scene, video loss, ...) |
| Audio | Built-in microphone / 1 Input |
| Audio Compression | G711A / U |
| Network interface | Ethernet 10 / 100M BaseT |
| Internal memory | MicroSD card up to 256GB |
| Remote access | Web Browser, Smartphone App Safire Smart, PC Software Safire Smart VMS |
| Interoperability | ONVIF |
| Power | DC 12 V / 625 mA / 7.5 W max. / IEEE802.3af PoE |
| Degree of protection | Weatherproof IP67 |
| Material | Metallic |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | 111.6 (Ø) × 99.6 (H) mm |
| Weight | 623 g |
In the box
- Safire Smart Turret IP Camera I1
- Installation material
- Installation quick guide
