SF-IPSD6525A-2P
- 2 MP Ultra Low Light Motorised IP Camera
- 1/2.8” Progressive Scan CMOS
- Compression H.265+/ H.265 / H.264+/ H.264
- 4.8~120 mm Lens (25X) Auto Iris
- Audio | Alarms | IP66
- Smart Tracking: Autotracking and events
- Safire
- Ultra Low Light IP PTZ Camera
- 25X Optical zoom
- 1/2.8" Progressive Scan CMOS
- 2 Megapixel (1920x1080)
- 4.8~120mm Varifocal Lens
- Colour 0.005 Lux / B&W 0.001 Lux
- Compression H.265+/H.265/H.264+/H.264
- RJ-45 10/100 BaseT
- WDR
- Video Analysis
- IR Cut
- Alarms
- Audio
- WDR
- Supports SD Memory Card
- PoE 802.3 at
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
- Impremeability IP66
Specifications
| Brand | SAFIRE |
| Image sensor | 1/2.8“ Progressive Scan CMOS |
| Resolution | 2 Mpx (1920x1080) at 25 FPS |
| Minimum illumination | 0.005 Lux (color) / 0.001 Lux (B/N)/ IR Filter (50 m) |
| Compression | H.265+/ H.265 / H.264+/ H.264 |
| Lens | 4.8~120 mm varifocal (Optical zoom 25X) H: 57.6º ~ 2.5º | V: 34.4º ~ 1.4º |
| Digital zoom | 16X |
| Electronic shutter | 1/1s~1/10,000s |
| Day / Night | Removable mechanical ICR filter |
| Image improvements | BLC, HLC, WDR, 3D-NR, AGC, AWB, MD, Privacy Masking, ROI |
| Video analysis | VCA: Line crossing | Intrusion in area | Audio exception | Autotracking |
| Pan/Tilt Range | Horizontal: 0°~360°, Vertical: -5°~90° auto flip |
| Manual speed | Horizontal: 0.1° ~ 300°/sec, Vertical: 0.1° ~160°/s |
| Speed between Presets | Horizontal: 160° /s, Vertical: 120° /s |
| Preset positions | 300 preset, 4 auto pattern, 8 auto tour, auto pan, auto scan |
| Internal memory | MicroSD card, Max 256 GB |
| Audio | 1 Input (Line In) / 1 Output (Line Out) |
| Alarms | 1 Input / 1 Relay |
| PTZ Control | Through network access |
| Network interface | Ethernet 10 / 100 BaseT |
| Remote access | Web browser, Safire Control Center Smartphone App and PC Software |
| Interoperability | ONVIF, PSIA, CGI |
| Power | DC 12V / 1.5A, PoE+ IEEE802.3at |
| Temp. operation | -30º C ~ +65º C |
| Degree of protection | IP66, Surges 6000V |
| Dimensions (without bracket) | 179.5 mm (H) x 165 (Ø) mm |
| Weight (without bracket) | 2000 g |
In the box
- SAFIRE Motorised IP dome camera
- Allen wrench
- Torx wrench
- Seal to RJ45
- CD with software and instructions
