RG-RAP62-Wall
RG-RAP62-Wall
- Reyee
- Omnidirectional Wi-Fi 6 Dual-Band AP
- Frequencies 2.4Ghz and 5Ghz
- Supports 802.11a/b/g/n/ac/ax
- Transmission speed up to 3000 Mbps
- MIMO antennas 2x2 at 2.4 GHz, 2x2 at 5 GHz
RG‑RAP62‑Wall is a wall-mounted Wi-Fi 6 (802.11ax) access point designed for indoor environments where a combination of high wireless performance, wired connectivity and wall-mounted aesthetics is required. Thanks to its plate-type design compatible with standard flush-mount boxes (86 × 86 mm), it integrates unobtrusively into offices, hotels, smart homes or commercial spaces without taking up visible ceiling or shelf space, offering wireless speeds of up to ~1.775 Mbps (574 Mbps at 2,4 GHz and 1.201 Mbps at 5 GHz) via dual-band MU-MIMO technology 2x2.
This equipment includes 1 Gigabit PoE-in port (802.3af/at) for power and data from a PoE switch or injector, along with 4 Gigabit LAN ports RJ45 (one of them with PoE-out function) that allow connecting and powering additional devices nearby, such as VoIP phones or IP cameras without extra sources. Supports advanced features such as centralized management via Ruijie Cloud, Reyee Mesh and intelligent roaming features to ensure continuous coverage, plus modern security options (Multi-SSID, WPA3, OFDMA, Beamforming) that optimize performance and the network experience in dense deployments.
Specifications
| Interface | 1 x RJ45 Base-T Port 10/100/1000/Mbps (Uplink) 4 x RJ45 Base-T Port 10/100/1000 Mbps |
| Brand | Reyee |
| Wireless standard | Wi-Fi 6 802.11ax |
| Frequencies | 2.4 GHz, 5GHz |
| Wi-Fi performance | Up to 300 Mbps Up to 573Mbps in 2.4GHz Up to 2401Mbps in 5GHz |
| Integrated antenna | 2.4 GHz , 2x2 MIMO 4.08dBi 5 GHz , 2x2 MIMO 5.40dBi |
| SSID | Up to 8 |
| Operating modes | Wireless access point Routers with basic functions Compatible with Reyee AP Mesh |
| Routing | Static IP, DHCP, PPPoE, NAT |
| Security | Isolated Wireless Clients, Block and Allow List. Authentication: WPA-PSK, WPA2-PSK, WPA/WPA2-PSK, WPA-Enterprise, WPA2-Enterprise, WPA/WPA2-Enterprise, OWE, WPA3-SAE, WPA2-PSK/WPA3-SAE |
| Management | Configuration via web or remote interface with Ruijie Cloud |
| Interface | 4 1Gbps (1000Base-T) RJ45 Ports |
| Functionalities | 802.1Q VLAN Port-based VLANs 802.11k/v/r, L2/L3 Roaming, AI Roaming Authentication 802.1X |
| Power | PoE 802.3af/at ( Poe Out only with PoE 802.3at ) |
| Maintenance and Diagnostics | Collection of failures in one click Active alarm for DHCP server conflicts Packet sniffing SNMP V1, V2c, V3 |
| Network technologies | RLDP DHCP snooping Wireless flow control (WQoS) Load balancing between access points Same SSID for different VLANs |
| Operating temperature | 0 °C ~ 40 °C |
| Dimensions | 125 mm × 86 mm × 23.5mm (Without anchorage kit) |
| Weight | 0,33 Kg (excluding mounting kit) |
In the box
- Access Point
- Installation guide
- Mounting Anchors
