IB-SH-REC-4
- Solar infrared barrier receiver
- 4 wireless inputs
- 4 wired outputs
- Up to 6 devices per input
- Dip Switch configuration
- Solar infrared barrier receiver
- 4 wireless input channels
- Up to 6 devices per input channel
- 4 wired outputs
- Simple configuration through the DIP Switch
- Long range
Specifications
| Inputs | 4 wireless inputs |
| Devices per input | 6 |
| Outputs | 4 wired outputs |
| Work frequency | 433MHz FSK+FHSS |
| Operating temperature | -30ºC ~ +70ºC |
| Power | DC 12V / 150mA max. |
| Dimensions | 140 (H) x 100 (W) x 55 (D) mm |
In the box
- Wireless receiver
- Installation material
- User instructions
