GJD509
- GJD External Laser Detector
- Laser technology with curtain-like coverage
- Detection range adjustable up to 10 m
- High reliability and precision
- Power supply 10~35 VDC
- Outdoor use
- GJD
- Outdoor Laser Detector
- Laser curtain coating technology
- Adjustable detection range up to 10 x 10 m
- Vertical coverage 90º
- High reliability and precision
- 3 beams IR detector
- Motion detection indicator
- Power supply 10~35 VDC
- Outdoor use
- Degree of protection IP65
Specifications
| Brand | GJD |
| Technology | Laser Technology |
| Detection range | Up to 10 x 10 m / 90º laser curtains for alarm and pre-alarm |
| Minimum target size | Depending on the distance to the detector: 2.1 cm at 3 m / 3.5 cm at 5 m / 7 cm at 10 m |
| Response time in detection | 20 ms |
| Emission characteristics | Wavelength: 905 nm (IR laser) / 650 nm (visible red laser during installation) |
| Tamper-resistant opening | Available |
| LEDs indication | ON/OFF, Alarm and Fault |
| Configuration | Configuration by remote control command GJD501 |
| Wired outputs | Alarm and Tamper |
| Installation | 3 visible laser beams to adjust the detection area and self-learning function |
| Power | 10 at 35 VDC |
| Average consumption | < 5 W |
| Temp. operation | -30 ºC ~ 60 ºC |
| Degree of protection | IP65 |
| Covered material | High quality PC/ASA plastic |
| Dimensions | 70 (H) x 93 (W) x 125 (D) mm |
In the box
- Outdoor laser detector
- Instructions Manual
- Installation material
