ZK-FHT2300D-316
- Bidirectional access turnstile
- 9 double rotating arms
- Times, alarms and opening modes
- Pitch dimensions 580 mm | Adjustable strength
- Made of corrosion resistant steel SUS316
- Compatible with third party systems
- ZKTeco
- Bidirectional two-access reel winch
- Semi-automatic rotary movement of the arms
- Pitch width of 580 mm on each side
- Led indicator
- Mechanical actuation force control system
- Emergency mode
- Main turnstile configuration board (opening times, counter, relay inputs)
- Made of corrosion resistant steel SUS316
- Configuration Modes: one- or two-way with Access Control, free passage in one or two directions
- Compatible with Plug & Play third-party access control systems
- Universal covers for card readers
Specifications
| Brand | ZKTeco |
| Model | FHT-FHT2300D-316 |
| Controller | Turnstile control board compatible with any Access Control system |
| Led indicator | LED status indicator |
| Arm movement | Mechanic Rotation of the arms (pushed by the user) |
| Emergency mode | Emergency power loss arm release |
| Security | Trio of 9 arms on each side / Anti-tailgating safety Mechanical actuation force control system |
| Compatibility | Integrates with any third party Plug & Play Access Control / Universal caps for RFID readers |
| Configuration Modes | One or two directions / Free passage in one direction and Access Control in the opposite direction mechanically configured |
| Manufacturing material | Anti-corrosion steel SUS316 |
| Passage speed | 20-25 persons/minute |
| Power | AC 110/220 V |
| Temp. operation | -28º C ~ +60º C |
| Lane Width | 580 mm |
| Dimensions of pass | 580 (w) x 990 (d) mm |
| Dimensions | 2220 (H) x 1395 (W) x 2018 (D) mm |
| Weight | 272 kg |
| Protection | Indoor / Outdoor (IP54) |
In the box
- ZKTeco reel turnstile
- Mounting material
- User instructions
- Security keys
