  • DVR 5n1 X-Security
  • 16 CH HDTVI/HDCVI/AHD/CVBS + 2 IP
  • Maximum resolution 1080p
  • Audio over coaxial
  • Advanced SMD motion detection
  • 1 HDD
  • X-Security
  • XVR 5n1
  • 16 HDTVI/HDCVI/AHD/CVBS video CH
  • 2+16 IP channels
  • 16 CH coax audio
  • 1 input / 1 audio output
  • H.265+/H.265/H.264+/H.264
  • Maximum resolution 1080p
  • PTZ Control (RS485/Coaxial)
  • Full HD HDMI and VGA Output
  • 64 Mbps bandwidth supported
  • SMD Plus: Advanced human- and vehicle-based motion detection (Up to 16 CH by the NVR itself)
  • Mouse
  • 2 USB Ports
  • Space for 1 HDD
  • ONVIF Compatible

Specifications

Brand X-Security
Video format HDTVI / HDCVI / AHD / CVBS / IP
Video inputs 16 Channels BNC (HDTVI / HDCVI / AHD / CVBS)
Hybrid configuration Up to 18 IP (6 Mpx channels), replacing all BNC channels
Video / audio compression H.265+/H.265/H.264+/H.264
Video input resolution CVI: 1080p to 25/30 fps; 720p to 25/30 fps.
TVI: 1080p to 25/30 fps; 720p to 25/30 fps.
AHD: 1080p to 25/30 fps; 720p to 25/30 fps.
Video outputs 1 HDMI Full HD, 1 VGA
Display resolution HDMI: 1920×1080, 1280×1024, 1280×720
VGA: 1920×1080, 1280×1024, 1280×720
Total bandwidth 64 Mbps
Coding Main flow:
Channel 1: 1080N/720p@(1 fps–25/30 fps)
Other channels: 1080N/720p@(1 fps–15 fps); 960H/D1/CIF@(1 fps–25/30 fps)

Secondary flow: CIF@(1 fps–7 fps)
Video bitrate 32 kbps–4096 kbps
Simultaneous multifunction Pentaplex: Live, Recording, Playback, Backup and Remote Access
Audio inputs 16 BNC (coaxial audio)
1 Channel RCA
Audio outputs 1 Channel RCA
Bidirectional audio Reusing the audio input/output
Audio Compression G.711a; G.711u; PCM
Audio bitrate 64 kbps
SMD (Advanced Motion Detection) Advanced motion detection based on human- and vehicle-induced pixel shift reducing false alarms
By NVR: Up to 16 CH
Per IP camera with SMD: All channels
Recording method Manual, programmed, motion detection, alarm
Backup USB / Network
Internal memory 1 SATA HDD 3.5" of up to 16 TB (not included)
Communication RS485 (PTZ)
1 x USB 2.0 (front), 1 x USB 2.0 (back)
RJ45 10/100 (Ethernet)
Remote access Web browser (ActiveX), mobile phone application or PSS software
Operating temperature –10 °C ~+55 °C
Power DC 12V / 2 A / <10 W (sin HDD)
Dimensiones 47.6 (Al) x 260 (An) x 237.8 (Fo) mm
Peso 1.13 kg

In the box

  • Grabador 5 en 1 X-Security
  • Ratón
  • Alimentador 12VDC
