XS-T887CA-3KE-DL
Ga direct naar de productinformatie
XS-T887CA-3KE-DL
- X-Security Dome Camera EASY range
- Output 4in1
- Resolution 5 MP (2880x1620)
- 2.8 mm Lens
- Dual Light range 40 m | Integrated Microphone
- IP67 | IK10 | Audio over Coaxial (CVI)
- X-Security
- HDTVI, HDCVI, AHD and Analog Dome Camera
- EASY Range
- Progressive Scan CMOS sensor
- Resolution 5 MP (2880x1620)
- Output 4in1
- 2.8 mm Lens
- 0 Lux
- Dual Light: IR and White Light
- Dual Light range 40 m
- IR Cut
- WDR (120 dB)
- 3D-DNR
- Integrated microphone
- Coaxial audio in HDCVI technology
- Weatherproof IP67
- Vandal proof IK10
- Surge protection
Specifications
| Brand | X-Security |
| Range | EASY |
| Image sensor | 5 MPx Progressive CMOS |
| Maximum resolution | 5 Mpx (2880x1620) |
| Resolution | CVI: 5Mpx (25~30 fps), 4Mpx (25~30 fps), 1080p (25~30 fps) TVI: 4Mpx (25~30 fps) AHD: 4Mpx (25~30 fps) CVBS: PAL/NTSC |
| Lens | 2.8 mm |
| Viewing Angle (FOV) | H: 112º, V: 58º, D: 136º |
| Range performance | 63.8 m (D), 25.5 m (O), 12.8 m (R), 6.4 m (I) |
| Lens Adjustment | 3-axis |
| Minimum illumination | 0.001 Lux @(F1.0, AGC ON) 0 lux with dual light |
| Supplementary lighting | Dual Light (IR + white light) range 40 m |
| Day / Night | Mechanical ICR filter |
| Electronic Shutter | 1/3~1/100000 s |
| Video output | 1 x BNC switchable between HDTVI / HDCVI / AHD / CVBS |
| Video output switching | By switch |
| Basic functions | OSD Menu |
| Image improvements | WDR (120 dB), 3D-DNR, Smart Light, BLC, HLC, AWB, AGC, Privacy Masking, Mirroring Effect |
| Audio | Integrated microphone Audio over coaxial cable in CVI technology |
| Power | DC 12 V / 6.4 W max. |
| Degree of protection | Weatherproof IP67, Anti-vandal IK10 Surge protection |
| Material | Metallic |
| Temp. operation | -40º C ~ +60º C |
| Dimensions | Ø 126 mm x 100 mm (H) |
| Base dimensions | Ø base 126 mm / Ø between bolts 110 mm / 3 bolts |
| Weight | 590 g |
In the box
- 4n1 X-SECURITY Dome Camera
- 3 plugs and 3 screws for mounting
- Installation template
- User instructions
