XS-SWI1108HIPOE-G120DIN
- Industrial Switch X-Security
- 8 ports RJ45 + 2 SFP ports + 1 RJ45 port
- Speed 10/100/1000Mbps
- 2x HiPoE + Ports 6x PoE+ Ports
- Total PoE power 120W
- DIN Rail Installation
- X-Security
- Industrial Switch
- 8 RJ45 10/100/1000 Mbps ports + 2 Gigabit SFP port + 1 Gigabit RJ45 Uplink port
- Energy Saving Technology
- Ports 1 and 5 up to 60W, Total Consumption 120W
- Din rail mounting
Specifications
| Interface | 8 PoE ports RJ45 + 2 SFP Ggiabit ports + 1 Gigabit port RJ45 |
| Port speed | 8 x 10/100/1000 Mbps BaseT (PoE) 2 x 1000 Mbps BaseX 1 x 10/100/1000 Mbps BaseT |
| PoE characteristics | Ports 1,2 up to 90W 802.3af/at/bt Ports 3-8 up to 30W 802.3af/at Total PoE power 120W PoE Extended up to 250m |
| Installation | DIN rail |
| Power | DC 48 V - 57 V |
| Operating temperature | -30º C ~ 65º C |
| Dimensions | 110 (D) x 42 (H) x 150 (W) mm |
In the box
- Industrial Switch X-Security
- AC/DC Power adaptor
- User instructions
