XS-NVR6432A-MIND
Ga direct naar de productinformatie
XS-NVR6432A-MIND
- X-Security NVR WizMind
- Maximum resolution 32 Megapixel
- 32 CH
- Compression H.265 / H.264 | 4 HDD
- HDMI output 4K | Alarm Outputs
- SMD, IVS, Metadata and AcuPick
- X-Security
- NVR for IP cameras
- 32 CH of video
- Maximum resolution 32 Megapixel
- Smart Compression H.265+ / H.264
- Alarm inputs and outputs
- VGA and HDMI 4K output
- Space for 4 HDD
- 384 Mbps bandwidth supported
- SMD Plus: Advanced human- and vehicle-based motion detection (Up to 8CH by the NVR itself)
- IVS: classification of human and vehicle (up to 24CH by the NVR itself)
- Facial recognition (Up to 32CH by the NVR itself)
- AcuPick: Intelligent search for a specific target based on human and vehicle from AI events with high accuracy
- Video metadata: Search for attributes of humans, vehicles and non-motorized vehicles (up to 8CH by the NVR itself)
- Intelligent target search
- ONVIF Compatible
Specifications
| Brand | X-SECURITY |
| Inputs for IP cameras | LAN port up to 64 channels |
| PoE | 16 PoE ports IEEE802.3at/af |
| IP compatible cameras | X-SECURITY (proprietary protocol), ONVIF |
| Video outputs | 1 HDMI 4K, 1 VGA |
| Video compression format | H.265+ Smart / H.265 / H.264+ / H.264 / MJPEG |
| Bidirectional audio | 1 input, 1 output, RCA |
| Recording resolution | 32MP, 16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 960p, 720p, D1, CIF |
| Decoding capacity | AI Disabled: 2CH to 32MP@30FPS, 2CH to 24MP@30FPS, 4CH to 16MP@30FPS, 5CH to 12MP@30FPS, 8CH to 8MP@30FPS, 4CH to 10MP@30FPS, 12CH to 5MP@30FPS, 16CH to 4MP@30FPS, 32CH to 1080p@30FPS AI Enabled: 1CH to 32MP@30FPS, 1CH to 24MP@30FPS, 2CH to 16MP@30FPS, 4CH to 12MP@30FPS, 6CH to 8MP@30FPS, 8CH to 6MP@30FPS, 8CH to 5MP@30FPS, 12CH to 4MP@30FPS, 24CH to 1080p@30FPS |
| Video output | 2 HDMI up to 4K 2 VGA up to 1080P |
| Display resolution | HDMI 1 and 2: 3840×2160, 1920×1080, 1280×1024, 1280×720 VGA 1 and 2: 1920x1080, 1280×1024, 1280×720 *HDMI 1 and HDMI 2 output are independent *HDMI 1 and VGA 1 output are independent *HDMI 2 and VGA 2 output are independent |
| Bandwidth | AI Disabled: 512 Input Mbps / 512 Output Mbps AI Enabled: 200 Input Mbps / 200 Output Mbps |
| SMD (Advanced Motion Detection) | Advanced motion detection based on human- and vehicle-induced pixel shift reducing false alarms By NVR: Up to 8CH Per IP camera with SMD: All channels (Up to 32 targets/second) |
| IVS Perimeter Protection | Intelligent algorithm based on human and vehicle detection with high accuracy filtering out any objects of no interest in the environment such as rain, leaves, bright lights, etc. IVS is based on line crossing, area intrusion, region of entry, ... By NVR: Up to 4CH (Up to 10 IVS rules) By IP camera with IVS: All channels (16 targets/second) |
| Facial Detection | Detection of facial attributes such as: Gender, age group, eyeglasses, expressions, mask or beard For the NVR: Up to 2CH (Up to 12 images/second per channel) By IP camera with Face Detection: Up to 16CH (Up to 12 targets/second) |
| Facial Recognition | Up to 20 face databases with 2.000.000 images (44G) Second screen with 4K enabled: 32ch Det. facial per camera + Rec. NVR Facial 4ch Det. facial by NVR + Rec. NVR Facial Second screen with 4K disabled: 32ch Det. facial per camera + Rec. NVR Facial 8ch Det. facial by NVR + Rec. NVR Facial By IP camera with facial recognition: Up to 32CH |
| AcuPick | Fast target search up to 32CH of humans and vehicles over live video or IVS Perimeter Protection event-based recording |
| Video metadata | By NVR: Up to 8CH Per IP camera with video metadata: Up to 32CH Feature extraction from 9 human attributes, 9 vehicle attributes and 4 non-motorized vehicle attributes |
| Intelligent event searches | SMD, IVS, Face Detection, Face Recognition, ANPR, People Counting, Heat Mapping |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | 4 Inputs / 2 Outputs NO/NC |
| Audio | 1 Input RCA / 1 Output RCA |
| Recording method | Manual, programmed, motion detection, alarm |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network / SATA |
| Internal memory | 4 HDD SATA 3.5" of up to 20TB (not included) |
| Communication | 3x USB (Mouse and backup) / 1xRS232 / 1xRS484 / 1 RJ45 10/100/1000M (Ethernet) |
| Racking | 1.5U |
| Remote access | Browser (ActiveX), Mobile phone application, DSS or DSS PRO software |
| Power | AC 100~240 V, 50/60 Hz, >10W |
| Operating temperature | –10 °C to +55 °C, 10%-93% (RH, non-condensing) |
| Dimensions | 53 (H) x 375 (W) x 329.3 (D) mm / 2.6 Kg |
In the box
- X-SECURITY NVR
- Mouse
- Ethernet Cable
- Power supply cable
- User instructions
- CD with manual and software
