XS-IPT982CA-8P-WIZCOLOR
Ga direct naar de productinformatie
XS-IPT982CA-8P-WIZCOLOR
- X-Security Turret Wizcolor IP camera
- 8 Megapixel (3840×2160) | 1/1.8" F1.0 Sensor
- Lens 2.8mm | White light 30m
- WDR 120dB | Built-in microphone
- WizSense, with human and vehicle classification
- MicroSD 256GB IP67
- X-Security
- Turret WizColor IP Camera
- PRO Range
- 1/1.8" Progressive CMOS
- 8 Megapixel (3840×2160)
- 2.8mm lens
- Minimum illumination 0.0008 lux@F1.0
- White light 30 m
- Compression H.265; H.264; H.264H; H.264B; MJPEG
- RJ-45 10/100M BaseT
- SMD Plus
- IVS WizSense: classification of human and vehicle
- Intelligent search
- Built-in microphone
- Audio
- WDR 120dB
- MicroSD up to 256GB
- PoE IEEE802.3af
- Weatherproof IP67
- ONVIF and CGI support
Specifications
| Brand | X-SECURITY |
| Maximum resolution | 8 Megapixel (3840×2160) |
| Image sensor | 1/1.8” Progressive CMOS |
| Lens | 2.8mm |
| Main Stream rate | 3840×2160@(1–20 fps) 2688×1520@(1–25/30 fps) |
| Extra Stream rate | 704×576@(1–25 fps) 704×480@(1–30fps) |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| Range performance | D: 84 m O: 33.6 m R: 16.8 m I: 8.4 m |
| FOV | 110°(H); 59°(V); 131°(D) |
| Led Scope | 30 m (White light) |
| Minimum illumination | 0.0008 lux@F1.0 |
| Image improvements | WDR 120 dB, BLC, HLC, AWB, AGC, 3D-NR, ROI |
| SMD Plus | Yes (Human and vehicle based motion detection) |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support the accurate classification and detection of vehicles and persons) |
| Wizcolor | True-color images 24/7 even in low light and dark conditions. |
| Intelligent search | Using microSD card or NVR X-Security |
| Network interface | Ethernet 10/100M BaseT |
| Audio | 1 Input / Built-in microphone |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Remote access | WEB, CMS (Smart PSS Lite / DSS / DMSS), Smartphone and NVR interface |
| Internal memory | MicroSD up to 256GB |
| Material | Metal and plastic |
| Interoperability | ONVIF (Profile S/Profile T); CGI |
| Power | DC 12 V PoE IEEE802.3af |
| Temp. operation | -40º C ~ +60º C |
| Degree of protection | Weatherproof IP67 |
| Dimensions | 109.5 (D) x 109.9 (Φ) |
| Weight | 420 g |
In the box
- X-Security Turret Wizcolor IP camera
- Installation material
- User instructions
- CD with software and instructions
