XS-IPT224S-4PW-TIOC
- Turret IP camera 4Mpx PRO range
- Smart Dual Light Range 30m | Active Deterrence
- 2.8 mm Lens
- AI: detection and classification of persons
- Microphone and speaker : MicroSD
- Wifi IEEE802.11b/g/n | Waterproof IP67
- X-Security
- Turret IP Camera
- PRO Range
- 1/3" CMOS
- 4 Megapixel (2560x1440)
- 2.8 mm Lens
- Dual Light: IR and white light
- Dual light range 30 m
- IR Cut
- Compression H.265/H.264/H.264H/H.264B
- Active Deterrence
- Intelligent functions: detection and classification of persons
- Built-in microphone and speaker
- MicroSD card slot up to 256 GB
- WEB, CMS (DSS/ Smart PSS/ DMSS), Smartphone and NVR interface
- RJ-45 10/100 BaseT
- ONVIF Compatible
- Wifi IEEE802.11b/g/n
- Weatherproof IP67
Specifications
| Brand | X-Security |
| Range | PRO |
| Image sensor | 1/3" CMOS |
| Maximum resolution | 4 Megapixel (2560x1440) |
| Main Stream rate | 2560x1440 @ (1–30 fps) |
| Extra Stream rate | 640x480 @ (1–30 fps) |
| Compression | H.265; H.264; H.264H; H.264B |
| Lens | 2.8 mm |
| Viewing Angle (FOV) | H: 98º, V: 55º, D: 115º |
| Minimum illumination | 0 lux with dual light |
| Supplementary lighting | Dual light (IR + white light) range 30 m |
| Day / Night | Removable mechanical ICR filter |
| Electronic shutter | 1/3 s–1/100.000 s |
| Image improvements | Smart Dual Light, Flip 180º |
| Audio | Built-in microphone and speaker |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Smart Features | Detection and classification of persons |
| Network interface | Ethernet 10/100 BaseT Wi-Fi IEEE802.11 b/g/n |
| WiFi frequency | 2.4–2.4835 GHz |
| Internal memory | MicroSD card slot up to 256 GB |
| Remote access | Web browser, CMS Software (DSS/PSS), Smartphone (DMSS) and NVR |
| Power | DC 12V / 7.1W |
| Temp. operation | -40º C ~ +60º C |
| Material | Metal and plastic |
| Degree of protection | Weatherproof IP67 |
| Dimensions | Ø 109.9 mm x 102.2 (H) |
| Weight | 353 g |
In the box
- X-SECURITY IP camera
- Mounting screws
- Installation template
- User instructions
- CD with software and instructions
- Power adapter
