XS-IPP5D-5EW-DL-TANDEM
Ga direct naar de productinformatie
XS-IPP5D-5EW-DL-TANDEM
- X-Security IP tandem Wi-Fi
- Dual Lens (Panoramic 5Mpx + PT 5Mpx))
- PT Lens 6 mm | Panoramic lens 2.8 mm
- Dual Light 50 m | IVS | SMD
- Built-in microphone and speakerphone | MicroSD | IP66
- AutoTracking | Siren and flash deterrent
- X-Security
- Wi-Fi range
- PT tandem IP camera + fixed lens panoramic camera
- PT sensor 1/3" Progressive Scan CMOS
- Resolution PT 5 Megapixel (2880x1620)
- PT Lens 6 mm
- Panoramic Sensor 1/3" Progressive Scan CMOS
- Resolution Panoramic 5 Megapixel (2880x1620)
- Panoramic Lens 2.8 mm
- 0 lux
- Dual Light: IR and white light
- IR Range PT 50 m
- IR Panoramic Range 30 m
- DWDR
- Compression H.265
- IR Cut
- IVS perimeter protection
- SMD Smart Search
- Built-in microphone and speaker
- Siren and strobe light
- Auto Tracking
- RJ-45 10/100 BaseT
- Wi-Fi IEEEE 802.11b/g/n/ax
- Wi-Fi pairing via Bluetooth
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
- MicroSD slot up to 256 GB
- Weatherproof IP66
- Wall bracket included
Specifications
| Brand | X-Security |
| Range | Wi-Fi |
| Image sensor | PT: 1/3“ Progressive Scan CMOS Panoramic: 1/3“ Progressive Scan CMOS |
| Resolution | PT: 5 Megapixel (2880x1620) Panoramic: 5 Megapixel (2880x1620) |
| Main Stream rate | 2880x1620 @15 fps |
| Extra Stream Rate 1 | 640x360 @15 fps |
| Compression | H.265 |
| Bitrate | 768 kbps–4096 kbps |
| Lens | PT: 6 mm Panoramic: 2.8 mm |
| Viewing Angle (FOV) | PT: H: 49º, V: 26º, D: 57º Overview: H: 95º, V: 53º, D: 110º |
| Day / Night | Removable mechanical ICR filter |
| Auto Focus | Semi-auto, Manual or Auto |
| Image improvements | DWDR |
| SMD (Smart Motion Detection) | Advanced SMD motion detection |
| IVS (Perimeter protection) | Intrusion, tripwire (both functions support the accurate classification and detection of vehicles and persons) |
| Pan/Tilt Range | PT: Horizontal: 0~352°, Vertical: 0~90° Overview: -10°~15° |
| Preset positions | 300 preset, 5 auto pattern, 8 auto tour, auto pan, auto scan |
| Auto Tracking | Yes |
| Internal memory | MicroSD card slot up to 256 GB |
| Audio | Built-in microphone and speaker Siren and strobe light |
| Audio Compression | G.711a |
| PTZ Control | Through network access |
| Network interface | Ethernet 10 / 100 BaseT Wi-Fi IEEE802.11 b/g/n/ax (Bluetooth pairing) |
| WiFi frequency | 2.412-2.472 GHz |
| Remote access | CMS (DMSS/DSS Pro), Smartphone and NVR |
| Power | DC 12 V, max. 10.6 W |
| Temp. operation | -20º C ~ +50º C |
| Material | Plastic |
| Degree of protection | Weatherproof IP66 |
| Dimensions (without bracket) | 210 mm (H) x 159.4 mm (D) x 119.1 mm (W) |
| Weight (without bracket) | 585 g |
In the box
- X-Security Motorized IP Dome Camera
- Allen wrench
- CD with software and instructions
- Wall bracket included
