VCA-ASP503
- VCA Technology VCAserver AI based analytics
- Model VCA-ASP503
- AMD Ryzen 9 7900 - 32GB RAM
- Nvidia RTX 5060 8GB - 512GB M.2 NVMe
- O.S. Linux Ubuntu 22.04 LTS
- Does not include video analysis licenses
- VCA Technology
- VCA Technolopgy AI Based Analytics server ASP503
- AMD Ryzen 9 7900
- Nvidia RTX 5060 8GB
- 500GB M.2 NVMe
- HD 8TB
- O.S. Linux Ubuntu 22.04 LTS
- Gigabit LAN RJ45
- Does not include video analysis licenses
Specifications
| Brand | VCA Technology |
| Range | VCA AI server |
| Model | VCA-ASP503 |
| CPU module | AMD Ryzen 9 7900 |
| GPU module | Nvidia RTX 5060 8GB |
| Storage | 512GB M.2 NVMe (O.S.) 8TB HD |
| Operating system | Linux Ubuntu 22.04 LTS |
| UBS ports | 4 x USB 3.2 Gen 1 (Type-A) 2 x USB 2.0 (Type-A) |
| Ethernet | 1 x Realtek Gigabit RJ45 |
| Integrated VCA events | Intrusion, tamper, zone entry/exit, appear/disappear from zone, stop in zone, dwell time, direction, people counting, object left, object removed, zone crossing and line crossing, speed, logical rules |
| AI video analytics supported | VCA stream (15fps@640x480) DL Object Tracker: Up to 100 channels DL People Tracker: Up to 100 channels DL Skeleton Tracker: Up to 95 channels DL Fisheye Tracker: Up to 75 channels HOI Tracker: Up to 108 channels Fall detection: Up to 69 channels Fight detection: Up to 53 channels Detection of PPE accessories: Up to 20 channels |
| Construction material | Metal and plastic, silver and black |
| Power | AC100V ~ 240V, 50-60Hz |
| Consumption | 800W |
| Operating conditions | 0°C ~ 40°C Humidity 20% ~ 85% RH (non-condensing) |
| Housing | Rack mounting 19" 2U |
| Dimensions | 488mm x 88.8mm x 600mm |
| Weight | 14.6kg. |
| Warranty | 3 years |
In the box
- Equipment VCA-ASP503
- Installation manual and quick guide
- European power cable
