UV-XVR-104F
Ga direct naar de productinformatie
UV-XVR-104F
- XVR Uniarch 5 in 1
- Uniarch | UMD
- 4 CH HDTVI / HDCVI / AHD / CVBS + 2 extra IP
- Supports 1 hard disk up to 6TB
- Maximum resolution 2 Analog MP
- Maximum resolution 6 MP IP
- Uniarch
- DVR 5n1
- 4 BNC video CH (IP-replaceable)
- AHD, TVI, CVI, CVBS, CVBS
- 24 Mbps bandwidth supported
- Maximum IP resolution 6 MP
- Maximum analog resolution 1080P
- Audio
- HDMI and VGA output
- 2 x USB 2.0
- Mouse
- Space for 1 HDD up to 6 TB
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
Specifications
| Brand | Uniarch |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 4CH BNC |
| Hybrid configuration | 4 CH Analog + 2 CH IP Up to 6 IP channels (6 MP) replacing all BNC channels |
| Video outputs | 1 HDMI Full HD, 1 VGA |
| Display resolution | 1920x1080, 1600x1200, 1280x1024, 1280x720, 1024x768 |
| Maximum IP recording resolution | 6 MP |
| Analog cameras supported | TVI \AHD \CVI :1080P@30FPS;720P@30FPS Supports CVBS |
| Main Stream recording encoding | TVI/CVI/AHD: 1080P Lite@25fps, 720P@30fps |
| Extra Stream recording encoding | D1@25FPS; D1@30FPS |
| Recording method | Manual, programmed, motion detection |
| UMD | Support in 4CH analogs |
| VCA Search | Support |
| Internal memory | 1 HDD SATA 3.5" of up to 6TB (not included) |
| External interface | 2 x USB (Mouse and backup) / RJ45 10M/100M/1000M (Ethernet) / RS485 |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Power | DC 12 V /10 W |
| Dimensions / Weight | 42 (H) x 190 (W) x 202 (D) mm / 0.6 kg |
In the box
- 5 in 1 Uniview recorder
- Mouse
- Power adapter
