UV-UHO-S3S-M33F36D
UV-UHO-S3S-M33F36D
- Uniarch Panda S-Series WiFi IP camera
- 3 MP | 2.8 mm + 6 mm | microSD 512 GB
- IR 10 m | White light 10 m
- Panoramic camera + PT Camera
- UMD | Cry and Pet Detection
- Bidirectional audio: Mic & Speaker
The Uniarch Panda S camera is the ideal solution to protect your home with state-of-the-art technology. Equipped with dual lenses - one panoramic lens for overview and one PT lens for capturing details - provides full coverage of the surroundings. Thanks to its artificial intelligence, it detects the movement of people, vehicles and pets, and even recognizes babies' cries, providing accurate and useful alerts. Flexible connectivity via WiFi or cable RJ45, along with two-way audio, built-in microphone and speaker, allows you to communicate in real time from anywhere. In addition, it features infrared and white light night vision with a range of up to 10 meters, ensuring clear images even in total darkness. Smart, easy-to-use security for peace of mind.
- Uniarch
- PT IP Dome Camera
- 1/2.8" Progressive Scan CMOS
- 3 Megapixel (2304x1296)
- Panoramic lens 2.8 mm and PT 6 mm
- IR range of 10 m
- White light range 10 m
- Ultra compression H.265/H.265/H.264
- WiFi IEEE802.11b/g/n/ax
- RJ-45 10/100 BaseT
- Ultra Motion Detection (UMD)
- Pedestrian/Motor Vehicle/Pet Detection
- Loud sound detection
- Cry detection
- Includes Microphone and Speaker
- MicroSD card slot up to 512 GB
- WEB, CMS, Smartphone and NVR interface
- 5 V / 1.5 A
- USB Type-C interface
Specifications
| Range | Uniarch |
| Image sensor | 1/2.8” Progressive Scan CMOS |
| Day / Night | Mechanical ICR filter |
| Maximum resolution | 3 Megapixel (2304x1296) |
| Lens | Fixed: 2.8 mm (Panorama) PT: 6 mm (Detail) (Dual lens is equivalent to a single IP address and occupies 2CH of video on an NVR) |
| FOV | Panorama: Horizontal: 109.2º Vertical: 57.9º Diagonal: 117.8º Detail: Horizontal: 55.1º Vertical: 29.3º Diagonal: 62.6º |
| Range performance | Panorama: D: 51.4 m O: 20.6 m R: 10.3 m I: 5.1 m Detail: D: 110.2 m O: 44.1 m R: 22 m I: 11 m |
| Main Stream rate | 3MP (2304*1296)@15fps 2MP (1920*1080)@15fps 720P (1280*720)@15fps |
| Extra Stream rate | 640*360@15fps 2CIF(704*288)@15fps CIF(352*288)@15fps |
| Compression | Ultra H.265/H.265/H.264 |
| WDR | DWDR |
| WIFI | 2.4G Wi-Fi IEEE802.11b/g/n/ax |
| Infrared range | 10 m |
| White light range | 10 m |
| PT Range | Pan 0° ~ 355° Tilt -15° ~ 90° |
| Internal memory | MicroSD card slot up to 512 GB |
| Intelligent detection | Human, vehicle, pet, baby crying and loud noise detection. |
| Alarms | Does not have |
| Audio | Includes microphone and speaker |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Power | DC 5 V / 1.5 A USB Type-C |
| Led indicator | 1, Red / Blue |
| Temp. operation | -10º C ~ 50º C |
| Dimensions | Ø80 x 127 (h) mm |
In the box
- Uniarch IP Camera
- Installation material
- User instructions
