UV-OEU-202S-HMK4
- IP video intercom system 4 apartments
- 2 MP Camera | Bidirectional Audio
- Opening with MF card 2 relays
- Mobile App with or without monitor
- Suitable for outdoor use IP65 | IK08
- Surface mounting | PoE
- Uniview
- IP video intercom with 2 MP camera for 4 apartments
- Wide angle lens
- Built-in speaker and microphone
- IR night vision
- Conexión TCP/IP y RS485 - PoE IEEE802.3af
- MF Card Reader
- Remote monitoring via UNV-Link mobile app or indoor monitor
- Remote door opening
- Call status LED
- Surface mounting
- Retro-illuminated name tag
- Suitable for exterior IP65
- Anti-vandal IK08
Specifications
| Brand | Uniview |
| Model | OEU-202S-HMK4 |
| Operating system | Linux |
| Image sensor | 2 Mpx CMOS wide-angle IR |
| Image Functions | BLC / WDR / DNR |
| Viewing angle | H: 107º, V: 57º, D: 128º |
| Audio | Bidirectional audio with microphone and speaker |
| Access control | Door opening with MF card 13.56 MHz Up to 2.000 users and 10.000 cards |
| Keypad | 4 x mechanical call button with LED customization tag |
| Outputs | 2 x relay for lock (2 x DC 12 V / 500 mA max.), 1 x RS485 |
| Inputs | 4 x auxiliary inputs (output button, feedback, door sensor), 1x Wiegand, 1 x tamper |
| Remote access | Web browser UNV-Link mobile application |
| Network interface | Ethernet 10/100 BaseT |
| Power | DC 12 V / 1000 mA máx. / IEEE802.3af PoE |
| Degree of protection | Suitable for exterior IP65 Anti-vandal IK08 |
| Material | Aluminium alloy |
| Temp. operation | -40 ºC ~ +60 ºC |
| Dimensions | 176 (H) x 96 (W) x 33 (D) mm |
| Weight | 675 g |
In the box
- Uniview Video Door Station Outdoor Panel
- Mounting material
- User instructions
