UV-NVR501-08B-P8-IQ

• Uniview NVR Prime - 8 PoE Channels
• Maximum resolution 16 MP
• 1 HDD up to 16 TB
• UMD | SIP | Face detection | Counting |
• AcuSearch | SmartSearch
• Bandwidth 80 Mbps

Network video recorder for 8 IP Prime range channels. Allows connection of 8 cameras via PoE ports and 1 HDD up to a maximum 16 TB. In addition to having compatibility with cameras that incorporate video analytics such as SIP or UMD, the recorder allows you to apply these analytics even if the cameras do not have the possibility to. In addition, it features SmartSearch and AcuSearch.

• NVR Recorder - Prime Range
• 8 video channels
• 8 PoE channels
• Decoding capacity: 2 x 16MP@30 fps | 2 x 12MP@30fps | 4 x 4K@30 fps
• Input bandwidth 80 Mbps
• Output bandwidth 80 Mbps
• Audio 1 Input / 1 Output
• HDMI output 4K
• VGA output 1080P
• VCA searches: motorized vehicle, non-motorized vehicle, human body, general search, people count report, heat map
• AcuSearch: Intelligent search in the recording where, starting from a frame of a person or vehicle, it allows to search in a determined time range and in the selected cameras within the same recorder the entire route in a chronological way.
• Supports IPC VCA: face detection, SIP, UMD, people counting on 4 channels
• Supports UMD on 8 channels and SIP on 4 channels, even for cameras that do not have these video analytics
• 1 HDD up to 16 TB
• 1 RJ45 10M/100M
• 1 USB port 2.0
• 1 USB port 3.0
• ONVIF Compatible

Specifications

In the box

• Uniview NVR
• Mouse
• Power supply cable
