UV-NVR501-04B-P4-A
Ga direct naar de productinformatie
UV-NVR501-04B-P4-A
- NVR for IP cameras
- Prime range
- 4 CH video / Ultra Compression H.265
- 4 PoE Channels
- Maximum resolution 8Mpx
- Bandwidth 80 Mbps
- Supports 1 hard disk up to 8TB
- Uniview
- NVR for IP cameras
- Prime range
- 4 CH
- 80 Mbps bandwidth supported
- Maximum resolution 4 K
- Smart features by camera
- Compression Ultra265/H.265/H.264
- Alarms
- VGA and HDMI 4K output
- Mouse
- Space for 1 HDD up to 8TB
- 4 PoE ports IEEE802.3af/at
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
Specifications
| Brand | Uniview |
| Range | Prime |
| Inputs for IP cameras | LAN port up to 4 channels |
| Power over Ethernet | Switch of 4 PoE ports IEEE802.3af/at |
| IP compatible cameras | UNIVIEW, ONVIF |
| Bidirectional audio | 1 input / 1 RCA output |
| Alarm | 4 inputs / 1 relay |
| Video outputs | 1 HDMI 4K, 1 VGA |
| Video compression format | Ultra H.265 / H.265 / H.264 |
| Display resolution | 3840x2160, 1920x1080, 1600x1200 1280x1024, 1280x720, 1024x768 |
| Total bandwidth | 80 Mbps downstream / 64 Mbps upstream |
| Smart features by camera | UMD, Person Counting, SIP (Smart Intrusion Prevention), Facial Detection, POS |
| Main Stream recording | 8Mpx / 6Mpx / 5Mpx / 4Mpx / 3Mpx / 1080p / 960p / 720p / D1 / 2CIF / CIF |
| Recording method | Manual, programmed, motion detection |
| External Backup | USB / HDD USB memory |
| Internal memory | 1 SATA HDD 3.5" of up to 8 TB (not included) |
| Communication | 1 x USB 2.0 , 1 x USB 3.0 / 1 x RJ45 (Ethernet) |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Power | DC 48V / 1.35 A |
| Dimensions / Weight | 260 (W) × 222 (D) × 47 (H) mm / 0.98 Kg |
In the box
- Uniview NVR
- Mouse
- Power supply cable
