UV-IPC7628EL-L-X41-VH1
Ga direct naar de productinformatie
UV-IPC7628EL-L-X41-VH1
- IP camera positioning 8 Megapixel
- Pro range
- 1/1.8” Progressive Scan CMOS
- 6~246mm (41X) lens
- IR LEDs Range 1000 m | WDR 120 dB
- WEB, CMS Software, Smartphone and NVR
- UNIVIEW
- IP Camera Positioning
- Pro range
- 41X Optical zoom
- 1/1.8" Progressive Scan CMOS
- 8 Megapixel (3840*2160)
- 6~246mm Varifocal Lens
- IR Range 1000 m
- Lighthunter
- Intelligent functions
- Ultra compression 265/H.265/H.264
- 1024 presets
- RS485
- Weatherproof IP66
- IR Cut
- WDR 120dB
- Audio
- Alarms
- Recording on SD card up to 512 GB
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
Specifications
| Brand | UNIVIEW |
| Image sensor | 1/1.8" Progressive Scan CMOS |
| Resolution | 8 Megapixel (3840*2160) |
| Main Stream rate | 8MP (3840*2160)@30fps |
| Sub Stream Rate | 2MP (1920*1080)@30fps |
| Third Stream Rate | D1 (720*576)@30fps |
| Minimum illumination | 0.0002 Lux (colour) |
| IR range | 1000 m |
| Compression | Ultra265/H.265/H.264 |
| Lens | Varifocal 6~246mm (Optic Zoom 41X) |
| Range performance | 155.5m~4829.4m (D), 62.2m~1931.8m (O), 31.1m~965.9m (R), 15.5m~482.9m (I) |
| Day / Night | Mechanical ICR filter |
| Image improvements | BLC, HLC, WDR, 2D/3D-NR, AGC, AWB, MD, Privacy Masking, ROI, ANR |
| Intelligent functions | False alarm reduction, people counting, line crossing detection, intrusion detection, area entry/exit, autotracking, etc |
| Pan/Tilt Range | Horizontal: 0°~360°, Vertical: -90°~45° |
| Manual speed | Horizontal: 0.1° ~ 140°/sec, Vertical: 0.1° ~ 50°/sec |
| Speed between Presets | Horizontal: 140° /s, Vertical: 50° /s |
| Preset positions | 1024 |
| Internal memory | MicroSD card, Max 512 GB |
| Audio | 1 Input / 1 Output |
| Alarms | 7 Inputs / 2 Outputs |
| Network interface | 1 x Ethernet 10 / 100 BaseT 1 x 100 M/1000 M SFP |
| Extra ports | Serial port RS485 and BNC |
| Remote access | EZStation Web Browser, Smartphone App and PC Software |
| Interoperability | ONVIF |
| Power | DC 48 V /AC 24 / 114W |
| Temp. operation | -40º C ~ +70º C |
| Degree of protection | Waterproof IP66 / Surge protection |
| Dimensions (without bracket) | 283mmx366mm x509mm |
| Weight (without bracket) | 15.42 kg |
In the box
- Uniview IP camera positioning
- Installation material
- User instructions
