UV-IPC6215SR-X5PAEW-VG
Ga direct naar de productinformatie
UV-IPC6215SR-X5PAEW-VG
- Uniview IP motorized camera - EasyStar range
- 5 MP | Motorized lens 2.7~13.5 mm (5X)
- IR 30 m | WDR 120 dB | microSD 512 GB
- LightHunter | Output 12VDC
- PoE+ | SIP | Wi-Fi
- Audio | Alarm | Microphone | Speakerphone | Speakerphone
Smart Intrusion Prevention (SIP)
With Uniview's SIP technology, stop threats before they happen thanks to its advanced intrusion prevention system. SIP combines artificial intelligence algorithms with real-time video analysis to accurately identify human and vehicular intrusions, minimizing false alarms caused by animal movements or weather conditions. Perfect for protecting perimeters, residential areas or critical facilities, ensuring intelligent and efficient security.
- UNIVIEW
- PTZ IP Camera
- EasyStar range
- 5X Optical zoom
- 1/2.7" Progressive Scan CMOS
- 5 Megapixel (2880x1620)
- 2.7~13.5 mm Varifocal Motorised Lens
- IR Range 30 m
- Ultra compression 265/H.265/H.264/MJPEG
- Smart Intrusion Prevention (SIP)
- 1024 presets
- PoE+ IEEE802.3at
- IR Cut
- WDR 120dB
- Audio
- Alarms
- Integrated microphone & speaker
- Recording on SD card up to 512 GB
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
- Output DC12V
Specifications
| Brand | UNIVIEW |
| Range | EasyStar |
| Image sensor | 1/2.7" Progressive Scan CMOS |
| Resolution | 5 Megapixel (2880x1620) |
| Minimum illumination | 0.003 Lux (colour) |
| Infrared lighting | 30 m |
| Compression | Ultra265/H.265/H.264 |
| Lens | Varifocal 2.7~13.5 mm (Optical Zoom 5X) |
| Digital zoom | 16X |
| Electronic shutter | 1/1s~1/100,000s |
| Day / Night | Mechanical ICR filter |
| Image improvements | WDR 120dB, BLC, HLC, EIS, 3D-NR, AGC, AWB, MD, Privacy Masking, ROI, ANR |
| Smart Features | Watermarking, IP address filtering, tampering alarm, alarm input, alarm output, access policy, ARP protection, RTSP authentication, user authentication |
| Pan/Tilt Range | Horizontal: 0°~350°, Vertical: -0°~90° auto flip |
| Speed | Horizontal: 0.1° ~ 60°/sec, Vertical: 0.1° ~50°/s |
| Preset positions | 1024 preset 16 patrols, 64 presets on each one |
| Smart Events | Motion detection, tampering alarm, audio detection, object removed, object forgotten, scene change, focus change detection |
| Smart Intrusion Prevention (SIP) | Line crossing, intrusion, area entry and exit (supports false alarm filtering and human and vehicle classification). |
| Internal memory | MicroSD card, Max 512 GB |
| Audio | 1 Input / 1 Output |
| Microphone | Support |
| Speaker | Support |
| Alarms | 1 Input / 1 Output |
| Wi-Fi | Support |
| Network interface | Ethernet 10 / 100 BaseT |
| Remote access | EZStation Web Browser, Smartphone App and PC Software |
| Interoperability | ONVIF, PSIA, CGI |
| Power | DC 12 V / 18W, PoE+ IEEE802.3at |
| DC output | Output DC12V embedded |
| Temp. operation | -10º C ~ +50º C |
| Dimensions | 143.6 mm (H) x 129 (Ø) mm |
| Weight | 780 g |
In the box
- Uniview Motorized IP Dome Camera
- Installation material
- Assembly instructions
