UV-IPC3615SB-ADF28KMC-I0
Ga direct naar de productinformatie
UV-IPC3615SB-ADF28KMC-I0
- Uniview Turret IP Camera - Prime range
- 5 MP | Lens 2.8 mm | microSD 512 GB
- IR 30m | White light 30m | WDR 120 dB
- Tri-Guard
- PoE | SIP | UMD | IP67 | People Counting
- MIC | Loudspeaker | Deterrent light | Alarms
5 MP Tri-Guard Prime Turret IP Camera. Integrates advanced analytics functions for accurate classification of people and vehicles, combined with active deterrence by emitting light and sound alerts, with options of pre-recorded or customized sounds.
- Turret IP Camera - Prime Range
- 5 MP (3072x1728)
- 2.8 mm Lens
- Minimum illumination: 0.002 lux
- 0 lux with supplementary light
- IR range of 30 m
- White light range 30 m
- People flow counting and crowd monitoring
- SIP (Smart Intrusion Prevention): combines artificial intelligence algorithms with real-time video analysis to accurately identify human and vehicular intrusions, minimizing false alarms caused by animal movements or weather conditions
- UMD (Ultra Motion Detection): thanks to its advanced AI algorithm, UMD is able to detect changes in the environment extremely efficiently, even in conditions of high speed or motion difficult to capture by other technologies
- Active deterrence: red and blue light in conjunction with siren to alert intruders
- Tri-Guard: Integrates SIP and active deterrence in a single IP camera. It will not only alert when an event occurs, but will have color information in dark environments. Tri-Guard includes red and blue light alert, which is more noticeable than white light
- WDR 120dB
- Integrated microphone
- Integrated speaker
- PoE
- Slot for Micro SD up to 512 GB
- IP67
- Metal and plastic
- ONVIF Compatible
Specifications
| Brand | Uniview |
| Range | Prime |
| Image sensor | 1/2.7” Progressive Scan CMOS |
| Maximum resolution | 5 Megapixel (3072x1728) |
| Lens | 2.8 mm |
| Viewing Angle (FOV) | H: 110º V: 58.7º D: 130º |
| Range performance | D: 63 m O: 25.2 m R: 12.6 m I: 6.3 m |
| Main Stream rate | 5MP (2880x1620)@30 fps; 4MP (2560x1440)@30 fps; 1080p (1920x1080)@30 fps; 720p (1280x720)@30 fps |
| Extra Stream rate | 720p (1280x720)@30 fps; D1 (720x76@30 fps; 640x360@30 fps; 2CIF (704x288)@30 fps; CIF (352x288)@30 fps |
| Compression | Ultra265/H.265/H.264 |
| Minimum illumination | Colour: 0,002 lux (F1.0, AGC ON) 0 lux with Supplementary light |
| Supplementary lighting | Hybrid light IR range: 30 m White light range: 30 m |
| Image improvements | WDR (120dB), BLC, HLC, AGC, 2D/3D-NR, ROI, Privacy Mask, Smart IR |
| SIP (Smart Intrusion Prevention) | Intelligent Intrusion Prevention. Accurate detection of humans and vehicles to avoid false alarms. Event due to line crossing, area intrusion or entry or exit of a previously defined area |
| Statistical analysis | People flow counting. Crowd density monitoring. |
| UMD | Integrates Ultra Motion Detection. |
| Intelligent functions | Motion Detection, Audio Detection, Sabotage Protection |
| Day / Night | Mechanical ICR filter |
| Internal memory | MicroSD card, Max 256 GB |
| Video Backup | ANR video recovery technology by installing a Micro SD card |
| Audio | Built-in microphone |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Interoperability | ONVIF |
| Power | DC 12 V / 7.5 W, PoE IEEE802.3af |
| Temp. operation | -30º C ~ 60º C |
| Material | Metal and plastic |
| Degree of protection | Waterproof IP67, Surge protection |
| Dimensions | Ø 111 x 95 (H) mm |
| Weight | 410 g |
In the box
- Uniview IP Camera
- Installation material
- User instructions
