UV-IPC3614LB-ADF28K-H
Ga direct naar de productinformatie
UV-IPC3614LB-ADF28K-H
- 4 MP IP Camera
- Easy range
- 1/2.9" Progressive Scan CMOS
- 2.8 mm Lens | IR LEDs range 30 m
- Integrated microphone
- WEB, CMS, Smartphone and NVR interface
Uniview Easy (-H) cameras with UMD (Ultra Motion Detection) technology stand out for their quality. UMD is an advanced function that allows to detect movements with an accuracy of 90%, a range of 15 meters and the possibility to configure up to 8 detection zones, minimizing false alarms.
- Uniview
- Turret IP Camera
- EasyBasic range
- 1/2.9" Progressive Scan CMOS
- 4 Megapixel (2560x1440)
- 2.8 mm Lens
- 0 Lux
- IR Range 30 m
- Compression Ultra265/H.265/H.264
- RJ-45 10/100 BaseT
- PoE IEEE802.3af
- Surge protection
- Slot for microSD up to 128GB
- Integrated microphone
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
- Weatherproof IP67
Specifications
| Brand | Uniview |
| Range | Easy |
| Image sensor | 1/2.9” Progressive Scan CMOS |
| Image resolution | 4 Megapixel (2688X1520) |
| Main stream rate | 4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 2MP (1920*1080), Max 30fps |
| Extra stream rate | D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
| Compression | Ultra 265, H.265, H.264, MJPEG |
| Lens | 2.8 mm |
| Minimum illumination | 0.01Lux ( F1.6, AGC ON) |
| Infrared range | 30 m |
| Image improvements | DWDR, BLC, HLC, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR |
| UMD | Supports ultra motion detection |
| Day/Night | Mechanical ICR filter |
| Internal memory | MicroSD card, Max 256 GB |
| Audio | Integrated microphone |
| Video backup | ANR video recovery technology by installing a Micro SD card |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Interoperability | ONVIF |
| Power | DC 12 V / 4 W, PoE IEEE802.3af |
| Operating Temp | -30º C ~ 60º C |
| Degree of protection | Weatherproof IP67 |
| Dimensions | Φ118 x 97mm |
| Weight | 300 g |
In the box
- Uniview IP Camera
- Installation tools
- User instructions
