UV-IPC3608SB-ADF16KM-I0
Ga direct naar de productinformatie
UV-IPC3608SB-ADF16KM-I0
- Uniview IP Bullet Camera - Prime range
- 8 MP | Lens 1.68 mm | microSD 512 GB
- IR 20m | Smart IR | WDR 120 dB
- Intelligent wide-angle : Dewarping
- PoE | SIP | UMD | IP67 | IK10
- Built-in microphone
Panoramic camera 180º with a lens of 1.68mm.
UMD (Ultra Motion Detection) is an advanced feature that allows the camera to detect movements generated only by humans or vehicles, thus filtering out movements of leaves, lights or headlights.
SIP (Smart Intrusion Prevention) allows to generate alerts of line crossing, intrusion, entrance and exit of area by detecting only humans and/or vehicles, which allows to filter false alerts.
- Uniview
- Turret IP Camera
- Prime range
- 1/2.7" Progressive Scan CMOS
- 8 Megapixel 3840x2160)
- Intelligent Wide Angle, Dewarping
- 1.68 mm Lens
- 0 Lux
- IR Range 20 m
- WDR 120dB
- Compression Ultra265/H.265/H.264/U-code
- Integrated microphone
- Intelligent functions
- UMD (Ultra Motion Detection)
- SIP (Smart Intrusion Prevention) with Color Retrieval
- PoE IEEE802.3af
- Slot for microSD 256Gb
- WEB, CMS, Smartphone and NVR interface
- ONVIF, RTSP support
- IK10
- Weatherproof IP67
- Surge protection
Specifications
| Brand | Uniview |
| Range | Prime |
| Image sensor | 1/2.7” Progressive Scan CMOS |
| Maximum resolution | 8 Megapixel (3840x2160) |
| Main Stream rate | 8MP (3840x2160), Max 30fps; 5MP (3072x1728), Max 30fps; 4MP (2560x1440), Max 30fps; 1080P (1920x1080), Max 30fps |
| Range performance | 37.8m(D) 15.1m(O) 7.6m(R) 3.8m(I) |
| Compression | Ultra265/H.265/H.264/U-code |
| Lens | 1.68 mm |
| Minimum illumination | 0.01 Lux (Colour) |
| Infrared range | 20 m |
| Image improvements | WDR (120dB), BLC, HLC, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR, Intelligent Wide Angle |
| Dewarping | Supported (1-9) |
| UMD (Ultra Motion Detection) | Yes (human and/or vehicle motion detection) |
| SIP (Smart Intrusion Prevention) | Yes (human and/or vehicle motion detection) Line crossover, intrusion, area entry and exit. |
| Intelligent functions | Line Crossing, Motion Detection, Ultra Motion Detection, Audio Detection, Tamper Protection, Hallway Mode |
| Day / Night | Mechanical ICR filter |
| Internal memory | MicroSD card, Max 512 GB |
| Video Backup | ANR video recovery technology by installing a Micro SD card |
| Material | Metallic |
| Audio | Integrated microphone |
| Network interface | Ethernet 10M/100M Base-TX |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Interoperability | ONVIF (Profile S/ Profile G/ Profile T), API ,SDK |
| Power | DC 12 V / 5.5 W, PoE IEEE802.3af |
| Temp. operation | -30º C ~ 60º C |
| Degree of protection | Weatherproof IP67 Vandal proof IK10 Over voltage protection 4KV |
| Dimensions | Ø 111 mm x 93 (H) mm |
| Weight | 480 g |
In the box
- Uniview IP Camera
- Installation material
- User instructions
