UV-IPC3534LB-ADZK-H-BLACK

UV-IPC3534LB-ADZK-H-BLACK

Log in voor B2B prijs
  • 4 MP IP Camera
  • EasyBasic range
  • 1/3" Progressive Scan CMOS
  • 2.8-12 mm motorised AF lens
  • IR LEDs Range 40 m
  • WEB, CMS, Smartphone and NVR interface

Uniview Easy (-H) cameras with UMD (Ultra Motion Detection) technology stand out for their quality. UMD is an advanced function that allows to detect movements with an accuracy of 90%, a range of 15 meters and the possibility to configure up to 8 detection zones, minimizing false alarms.

  • Uniview
  • IP Dome Camera
  • EasyBasic range
  • 1/3" Progressive Scan CMOS
  • 4 Megapixel (2688x1520)
  • 2.8-12 mm motorised varifocal autofocus lens
  • 0 Lux
  • IR Range 40 m
  • WDR 120dB
  • UMD (Ultra motion detection)
  • Supports corridor mode 9:16
  • Compression Ultra265/H.265/H.264
  • Integrated microphone
  • RJ-45 10/100 BaseT
  • PoE IEEE802.3af
  • MicroSD slot
  • WEB, CMS, Smartphone and NVR interface
  • ONVIF Compatible
  • Weatherproof IP67
  • Vandal proof IK10
  • Surge protection

Specifications

Brand Uniview
Range Easy
Image sensor 1/3" Progressive Scan CMOS
Maximum resolution 4 Megapixel (2688×1520)
Lens 2.8 ~ 12 mm, AF autofocus and power zoom lens
Main Stream rate 4MP (2688*1520)@25fps; 4MP (2560*1440)@25fps; 3MP (2304*1296)@25fps; 1080P
(1920*1080)@30fps;
Extra Stream rate 720P (1280*720)@30fps; D1 (720*576)@30fps; 640*360@30fps; 2CIF(704*288)@30fps;
CIF(352*288)@30fps;
Compression Ultra265/H.265/H.264
Minimum illumination Colour: 0.003 lux (F1.6, AGC ON)
0 lux with IR on
Infrared range 40 m
WDR 120 dB
Image improvements BLC, HLC, AGC, 2D/3D-NR, Smart IR, Region of interest, Privacy mask
Audio Built-in microphone
Detection functions Cross-line, intrusion (based on human body detection), motion detection, ultra-motion detection, tamper alarm, audio detection
Day / Night Mechanical ICR filter
Internal memory Micro SD slot (up to 256 GB)
Network interface Ethernet 10/100 BaseT
Remote access Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive)
Interoperability ONVIF (S-Profile, G-Profile, T-Profile)
Protection Waterproof (IP67), Vandal-proof (IK10), Surge protection
Power 8.W, PoE (IEEE 802.3af) PoE (IEEE [%VAR%])
Operating Temp -30°C ~ 60°C
Dimensions Φ128mmx100mm
Weight 660 g

In the box

  • Uniview IP Camera
  • Installation tools
  • User instructions
