UV-IPC328LE-ADF40K-H
Ga direct naar de productinformatie
UV-IPC328LE-ADF40K-H
- Uniview IP Dome Camera Easy Range
- 8 MP | Lens 4 mm | microSD 512 GB
- IR 30 m | WDR 120 dB
- Human-body-based line crossing and intrusion
- PoE | IP67 | IK10 | UMD
- Built-in microphone
Ultra Motion Detection (UMD)
Uniview's UMD technology takes motion detection to the next level, accurately identifying the fastest or subtlest movements. Thanks to its advanced AI algorithm, UMD is able to detect changes in the environment extremely efficiently, even in conditions of high speed or movement difficult to capture by other technologies. Perfect for applications such as surveillance of high traffic areas or protection of critical sites where every second counts.
- Uniview
- IP Dome Camera
- EasyStar range
- 1/2.8" Progressive Scan CMOS
- 8 Megapixel (3840x2160)
- 4 mm Lens
- 0 Lux
- IR Range 30 m
- Built-in microphone
- WDR 120dB
- Compression Ultra265/H.265/H.264
- RJ-45 10/100 BaseTX
- PoE IEEE802.3af
- Weatherproof IP67
- Vandal proof IK10
- Overvoltage 4KV
- Slot for microSD up to 512 GB
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
Specifications
| Brand | Uniview |
| Range | EasyStar |
| Image sensor | 1/2.8" CMOS Progressive Scan Starlight |
| Lens | 4 mm |
| Angle of view (FoV) | 98.7º (H), 53.9º (V), 103.6º (D) |
| Range performance | 86.9 m (D), 34.8 m (O), 17.4 m (R), 8.7 m (I) |
| Maximum resolution | 8 Megapixel (3840×2160) |
| Main Stream rate | 8MP (3840*2160)@20fps; 5MP (3072*1728)@30fps; 4MP (2560*1440)@30fps; 1080P (1920*1080)@30fps; |
| Extra Stream rate | 1080P (1920*1080)@30fps; 720P (1280*720)@30fps; D1 (720*576)@30fps; 640*360@30fps; 2CIF(704*288)@30fps; CIF(352*288)@30fps; |
| Video compression | Ultra265/H.265/H.264 |
| Audio Compression | G.711U, G.711A |
| Minimum illumination | 0.005 Lux (Colour) |
| Infrared range | 30 m |
| WDR | 120 dB |
| Events | Motion Detection, Ultra Motion Detection, Tamper Alarm, Audio Detection, Line Crossing (based on human body detection), Intrusion (based on human body detection) |
| Image improvements | Motion detection, BLC, HLC, AGC, 2D/3D-NR, Smart IR, Region of interest, Privacy mask |
| Audio | Built-in microphone |
| Day / Night | Mechanical ICR filter |
| Internal memory | Micro SD slot (up to 512 GB) |
| Network interface | Ethernet 10/100 BaseTX |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (UNV-Link, UNV-Link Pro) |
| Interoperability | ONVIF |
| Protection | Waterproof (IP67), Vandal resistant (IK10), Over voltage 4KV |
| Power | DC 12 V / 4.9 W, PoE IEEE802.3af |
| Temp. operation | -30º C ~ 60º C |
| Dimensions | 83 mm (D) x 111 (Ø) mm |
| Weight | 360 g |
In the box
- Uniview IP Camera
- Installation tools
- User instructions
