UV-IPC325LE-ADF28K-H
Ga direct naar de productinformatie
UV-IPC325LE-ADF28K-H
- IP Dome Camera 5 Megapixel EasyStar Range
- Lens 2.8 mm | 1/2.7" Progressive Scan CMOS
- Detection of persons, vehicles, line crossings, etc
- Metal and plastic body | IR range 30 m
- IP67, IK10, 4KV Protection
- Dimensions: Ø111 x 83 mm | Weight: 0.35 Kg
Uniview Easy (-H) cameras with UMD (Ultra Motion Detection) technology stand out for their quality. UMD is an advanced function that allows to detect movements with an accuracy of 90%, a range of 15 meters and the possibility to configure up to 8 detection zones, minimizing false alarms.
- Uniview
- IP Dome Camera
- EasyStar range
- 1/2.7" Progressive Scan CMOS
- 5 Megapixel (2880x1620)
- 2.8 mm Lens
- 0 Lux
- IR Range 30 m
- Audio
- WDR 120 dB
- Compression Ultra265/H.265/H.264
- RJ-45 10/100 BaseTX
- PoE IEEE802.3af
- Corridor mode
- Weatherproof IP67
- Vandal proof IK10
- Surge protection
- Slot for microSD up to 512 GB
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
- Integrated microphone
- 3 axis
Specifications
| Brand | Uniview |
| Range | EasyStar |
| Image sensor | 1/2.7" CMOS Progressive Scan Starlight |
| Maximum resolution | 5 Megapixel (2880×1620) |
| Main Stream rate | 5MP (2880x1620)@25fps; 4MP (2560x1440)@25fps; 3MP (2304x1296)@30fps; 1080P (1920*1080)@30fps; 720P (1280*720), Max 30fps |
| Extra Stream rate | 720P (1280x720)@30fps; D1 (720x576)@30fps; 640x360@30fps |
| Compression | Ultra265/H.265/H.264 |
| Lens | 2.8 mm |
| Angle of view (FoV) | 110º (H), 58.7º (V), 130º (H) |
| Range performance | 63 m (D), 25.2 m (O), 12.6 m (R), 9 m (I) |
| Minimum illumination | 0.003 Lux (Colour) |
| Infrared range | 30 m |
| WDR | 120 dB |
| Corridor mode | Yes |
| Audio | Integrated microphone |
| Image improvements | Motion detection, BLC, HLC, AGC, 2D/3D-NR, Smart IR, Region of interest, Privacy mask |
| Intelligent functions | Line crossing and intrusion based on person detection, Motion detection, Ultra motion detection, Anti-tampering, Audio detection |
| Day / Night | Mechanical ICR filter |
| Internal memory | Micro SD slot (up to 512 GB) |
| Network interface | Ethernet 10/100 BaseTX |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (UNV-LINK, UNV-LINK Pro) |
| Interoperability | ONVIF |
| Protection | Waterproof (IP67), Vandal-resistant (IK10), Surge protection 4KV |
| Power | DC 12 V / 4.4 W, PoE IEEE802.3af |
| Temp. operation | -30º C ~ 60º C |
| Material | Metal and plastic |
| Dimensions | 83 mm (D) x 111 (Ø) mm |
| Weight | 350 g |
In the box
- Uniview IP Camera
- Installation tools
- User instructions
