UV-IPC318SB-ADF28K-I0-BLACK
- Uniview IP Dome Camera - Prime range
- 8 MP | Lens 2.8 mm | microSD 512 GB
- IR 30 m | WDR 120 dB
- Light Hunter
- PoE | UMD | IK10 | IP67
- Built-in microphone : Black color
Dome type Prime IP camera of 8 MP, with 2.8 mm fixed lens. Thanks to its Light Hunter technology and its real WDR of 120 dB can obtain clear images in difficult lighting conditions. UMD to avoid false alarms in video analytics.
- Uniview
- IP Dome Camera - Prime Range
- 8 MP (3840x2160)
- 2.8 mm fixed lens
- Minimum illumination 0.002 lux | 0 lux with IR
- IR range of 30 m
- Light Hunter: technology that ensures super-high quality images in low-light environments
- UMD (Ultra Motion Detection): thanks to its advanced AI algorithm, UMD is able to detect changes in the environment extremely efficiently, even in conditions of high speed or motion difficult to capture by other technologies
- WDR 120 dB
- Built-in microphone
- Slot for microSD up to 512 GB
- PoE
- IP67
- IK10
- Metallic
- ONVIF Compatible
- Black colour
Specifications
| Brand | Uniview |
| Range | Prime |
| Image sensor | 1/3" Progressive Scan CMOS |
| Maximum resolution | 8 Megapixel (3840x2160) |
| Main Stream rate | 8 Mpx (3840x2160), maximum 20 fps; 5 Mpx (3072x1728), maximum 30 fps; 4 Mpx (2560x1440), maximum 30 fps; 1080P (1920x1080), maximum 30 fps |
| Extra Stream rate | 1080P (1920x1080), maximum 30 fps; 640x360, maximum 30 fps; 2CIF (704x288), maximum 30 fps; CIF (352x288), maximum 30 fps |
| Third Stream Rate | D1 (720x576), maximum 30 fps; 640*360, maximum 30 fps; 2CIF(704x288), maximum 30 fps; CIF (352x288), maximum 30 fps |
| Compression | Ultra265/H.265/H.264/MJPEG |
| Video Bitrate | 128 Kbps~16 Mbps |
| Lens | 2.8 mm |
| Viewing Angle (FOV) | H: 101.1º, V: 55.3º, D: 111.1º |
| Range performance | 63 m (D), 25.2 m (O), 12.6 m (R), 6.3 m (I) |
| Minimum illumination | LighHunter, high image quality in low-light environments 0.002 Lux (F1.6, AGC ON) 0 Lux with Infrared |
| Day / Night | Mechanical ICR filter |
| Infrared range | 30 m |
| Shutter | 1 ~ 1/100000s |
| Image improvements | WDR (120 dB), BLC, AGC, AWB, 2D/3D-DNR, Smart IR, ROI (Up to 8 areas), Privacy mask, Flip |
| UMD (Advanced Motion Detection) | Integrates Ultra Motion Detection. |
| Alarms | Does not have |
| Audio | 1 input / 1 output Integrated microphone |
| Audio Compression | G.711U, G.711A |
| Audio Bitrate | 64 Kbps |
| Network interface | Ethernet 10/100M BaseT |
| Internal memory | MicroSD card slot up to 512 GB |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Interoperability | ONVIF (Profile S, Profile G, Profile T), API, SDK |
| Power | DC 12V / 6W PoE IEEE802.3af |
| Temp. operation | -30º C ~ 60º C |
| Material | Metallic |
| Degree of protection | Weatherproof IP67 Vandal proof IK10 Surge protection 4000 V |
| Dimensions | 61 (H) x 110 (Ø) mm |
| Base dimensions | Ø base 110 mm / Ø between bolts 98 mm / 3 bolts |
| Weight | 370 g |
| Colour | Black |
In the box
- Uniview IP Camera
- Installation tools
- User instructions
