UV-IPC312SB-ADF28K-I0
- Uniview IP Dome Camera - Prime range
- 2 MP | Lens 2.8 mm | microSD 256 GB
- IR 30m | WDR 120 dB
- LightHunter | Statistical Analysis
- PoE | SIP | UMD | IP67 | IK10
- Audio | Mic
2 MP Prime IP Dome Camera with 2.8 mm Fixed Lens. Thanks to its Light Hunter technology and the fact that it has a real WDR of 120dB you can obtain clear images in difficult lighting conditions. Features SIP and UMD to avoid false alarms in video analytics.
- IP Dome Camera - Pro Range
- 2 MP (1920x1080)
- 2.8 mm fixed lens
- Minimum illumination 0.001 | 0 Lux with IR
- IR range of 30 m
- People counting, people flow counting and crowd density monitoring
- SIP (Smart Intrusion Prevention): combines artificial intelligence algorithms with real-time video analysis to accurately identify human and vehicular intrusions, minimizing false alarms caused by animal movements or weather conditions
- UMD (Ultra Motion Detection): thanks to its advanced AI algorithm, UMD is able to detect changes in the environment extremely efficiently, even in conditions of high speed or motion difficult to capture by other technologies
- WDR 120 dB
- Audio 1 Input / 1 Output
- Integrated microphone
- Slot for microSD up to 256 GB
- PoE
- Weatherproof IP67
- Vandal proof IK10
- Over voltage protection 4 KV
- Corridor mode 9:16
- ONVIF Compatible
Specifications
| Brand | Uniview |
| Range | Prime |
| Image sensor | 1/2.8" Progressive Scan CMOS |
| Maximum resolution | 2 Megapixel (1920x1080) |
| Main Stream rate | (1920x1080, 1280x720)@ 30FPS |
| Extra Stream rate | 720P(1280x720), D1 (720x576), 640*360 @30fps |
| Third Stream | D1 (720x576), 640x360, 2CIF(704x288), CIF (352x288) @30fps |
| Compression | Ultra265/H.265/H.264 |
| Lens | 2.8 mm |
| FOV | Horizontal: 106.7º Vertical: 57.1º Diagonal: 115.7º |
| Range performance | Detect: 43.4 m Observe: 17.4 m Recognize: 8.7 m Identify: 4.3 m |
| Minimum illumination | 0.001 Lux (F1.6, AGC ON) 0Lux with Infrared |
| Infrared range | 30 m |
| Day / Night | Mechanical ICR filter |
| Image improvements | BLC, HLC, AGC, 2D/3D-NR, Smart IR, ROI (Up to 8 areas), Privacy Masking |
| WDR | 120 dB |
| Corridor mode | Yes |
| UMD (Advanced Motion Detection) | Yes |
| Intelligent functions | SIP, Smart Intrusion Prevention (Classification of human, vehicle and two-wheeler over line crossing, area intrusion, region of entry and region of exit) Counting and flow of people over an area *Both functions cannot be enabled at the same time |
| Internal memory | Micro SD slot, up to 256 GB |
| Alarms | Does not have |
| Audio | Integrated microphone 1 Input / 1 Output |
| Network interface | Ethernet 10/100M BaseT |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Interoperability | ONVIF |
| Power | DC 12V / 6W PoE IEEE802.3af |
| Temp. operation | -30º C ~ 60º C |
| Dimensions | 61 (D) x 110 (Ø) mm |
| Weight | 370 g |
| Material | Metallic |
In the box
- Uniview IP Camera
- Installation tools
- User instructions
