UV-IPC264EA-AHDZK-I1
Ga direct naar de productinformatie
UV-IPC264EA-AHDZK-I1
- Uniview IP Bullet Camera - Pro range
- 4 MP | Motorized lens 2.8~12 mm | 4X Zoom
- IR 100m | WDR 140 dB | 60 FPS | microSD 512 GB
- Wise-ISP : Metadata : People counting
- SIP | UMD | IP67 | IK10 | PoE+
- Audio | Alarms | Mic | Loudspeaker | Reset
4MP IP Pro Bullet Camera with 2.8~12 mm motorized varifocal lens, 4X Optical Zoom and 60 FPS. Equipped with Wise-ISP technology, it features SIP, people counting and human and vehicle attribute capture for metadata storage. It also has WDR 140dB and 60fps for greater image detail.
- IP Bullet Camera - Pro Range
- 4 MP (2688x1520)
- 60 FPS
- Motorized varifocal lens 2.8~12 mm Autofocus
- Minimum illumination 0.0003 | 0 Lux
- IR range of 100 m
- Wise-ISP: with Uniview's Wise-ISP technology, your images will reach an exceptional level of perfection. This intelligent processor optimizes each frame by reducing noise, improving dynamic range and adjusting colors to deliver superior visual quality. Designed for scenarios with varying light conditions, Wise-ISP guarantees sharp and consistent images, becoming the basis for Uniview's most advanced solutions
- SIP (Smart Intrusion Prevention): combines artificial intelligence algorithms with real-time video analysis to accurately identify human and vehicular intrusions, minimizing false alarms caused by animal movements or weather conditions
- UMD (Ultra Motion Detection): thanks to its advanced AI algorithm, UMD is able to detect changes in the environment extremely efficiently, even in conditions of high speed or motion difficult to capture by other technologies
- Supports human body attribute collection, face capture, vehicle detection for metadata search process
- Supports people flow counting and crowding density
- WDR 140 dB
- Audio 2 Inputs / 1 Output
- Alarm 3 Inputs / 2 Outputs
- 2 Built-in microphones
- Integrated speaker
- Integrated Heater
- Slot for microSD up to 512 GB
- PoE+
- Weatherproof IP67
- Vandal proof IK10
- Over voltage protection 6 KV
- Reset button
- ONVIF Compatible
Specifications
| Brand | Uniview |
| Range | Pro |
| Image sensor | 1/1.8” Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2688 x 1520) |
| Lens | Motorized varifocal lens 2.8 ~ 12 mm |
| FOV | H: 106.6 ~ 51.3º V: 56.9 ~ 28.6 º D: 131.1 ~ 63.1 º |
| Range performance | D: 68 ~ 166.2 m O: 27.2 ~ 66.5 m R: 13.6 ~ 33.2 m I: 6.8 ~ 16.6 m |
| Main Stream rate | 4MP (2688x1520)@60fps |
| Extra Stream rate | 2º: 1080P (1920x1080)@60fps; 3º: D1 (720x576)@60fps |
| Compression | Ultra 265, H.265, H.264, MJPEG |
| Minimum illumination | Colour: 0,0003 lux (F1.6, AGC ON) 0 lux with activated IR |
| Infrared range | IR: 100 m |
| Image improvements | WDR (140dB), BLC, HLC, AGC, 2D/3D-NR, ROI, Privacy Mask, Smart IR |
| Intelligent intrusion prevention | False alarm filtering, cross-line detection, intrusion detection, entry area detection, exit area detection, motion detection, exception alarms |
| Detection | Audio detection. |
| Day / Night | Mechanical ICR filter |
| Internal memory | MicroSD card, Max 512 GB |
| Video Backup | ANR video recovery technology by installing a Micro SD card |
| Audio | 2 In / 1 Out |
| Alarm | 3 inputs / 2 relay |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Interoperability | ONVIF (S-Profile, G-Profile, T-Profile), API,SDK |
| Power | DC 12V / 16W PoE+ IEEE802.3at |
| Temp. operation | -40º C ~ 60º C |
| Degree of protection | Waterproof IP67 / Antivandalic IK10 / Overvoltage 6KV |
| Dimensions | 406 (D) x 126 (W) x 130 (H) mm |
| Weight | 1920 g |
In the box
- Uniview IP Camera
- Installation material
- User instructions
