UV-IPC2324LB-ADEZK-H
- Uniview IP Bullet Camera - Easy range
- 4 MP | Motorized lens 2.8~ 12 mm
- IR 50 m | WDR 120 dB | microSD 128 GB
- PoE | IP67 | UMD
- Microphone | Alarm | Audio
Easy Bullet type 4 MP IP camera with 2.8 ~ 12 mm motorized varifocal lens, Integrates SIP and UMD in video analytics to reduce false alerts and make recording searches faster.
- IP Bullet Camera - Easy Range
- 4 MP(2688x1520)
- Motorized varifocal lens 2.8 ~ 12 mm
- Minimum illumination 0.003 lux | 0 lux with supplemental light
- IR range of 50 m
- UMD (Ultra Motion Detection): thanks to its advanced AI algorithm, UMD is able to detect changes in the environment extremely efficiently, even in conditions of high speed or motion difficult to capture by other technologies
- WDR 120 dB
- Integrated microphone
- Audio 1 Input / 1 Output
- Alarm 1 Input / 1 Output
- Slot for MicroSD card up to 256 GB
- PoE
- IP67
- Corridor mode 9:16
- Graphene and metal
- ONVIF Compatible
Specifications
| Brand | Uniview |
| Range | EasyBasic |
| Image sensor | 1/2.8” Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2688x1520) |
| Main Stream rate | 4MP (2688x1520), Max 25fps; 4MP (2560x1440), Max 25fps; 3MP (2304x1296), Max 30fps; 1080P (1920x1080), Max 30fps; 720P(1280x720), Max 30fps; |
| Range performance | 2.8 mm: 43(D) 17(O) 8(R) 4(I) 12 mm: 186(D) 74(O) 37(R) 18(I) |
| Compression | Ultra265/H.265/H.264/U-code |
| Lens | 2.8 - Motorised 12mm |
| Minimum illumination | 0.003 Lux (F1.6, AGC ON) 0 Lux with IR ON |
| Infrared range | 50 m |
| Image improvements | WDR (120dB), BLC, HLC, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR |
| UMD | Ultra Motion Detection: Advanced motion detection with human and vehicle classification |
| Intelligent functions | Line Crossing, Intrusion (based on human body detection), Motion Detection, Audio Detection, Tamper Protection, Corridor Mode |
| Day / Night | Mechanical ICR filter |
| Internal memory | MicroSD card, Max 256 GB |
| Video Backup | ANR video recovery technology by installing a Micro SD card |
| Material | Graphene and metal |
| Audio | 1 Input / 1 Output Integrated microphone |
| Alarms | 1 Input / 1 Output |
| Network interface | Ethernet 10M/100M Base-TX |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Interoperability | ONVIF (Profile S/ Profile G/ Profile T), API ,SDK |
| Power | DC 12V / 9.6W PoE IEEE802.3af |
| Temp. operation | -30º C ~ 60º C |
| Degree of protection | Weatherproof IP67 |
| Dimensions | 73 (W) x 73 (H) x 206 (D) mm |
| Weight | 510 g |
In the box
- Uniview IP Camera
- Installation material
- User instructions
