UV-IPC2225SB-ADF28KM-I1
Ga direct naar de productinformatie
UV-IPC2225SB-ADF28KM-I1
- Uniview IP Bullet Camera - Prime range
- 5 MP | Lens 2.8 mm | microSD 256 GB
- IR 80 m | WDR 120 dB
- Light Hunter
- PoE | UMD | SIP | IP67 | IK10
- Mic | Alarm | Audio
5 MP Prime Bullet IP camera with 2.8 mm fixed lens. It has Light Hunter technology that together with the real WDR of 120 dB, makes its image quality superior. Additionally, it incorporates SIP and UMD to avoid false alarms.
- Uniview
- IP Bullet Camera - Prime Range
- 5 MP (2880x1620)
- 2.8 mm fixed lens
- Minimum illumination 0.003 lux | 0 lux with IR
- IR range of 80 m
- Light Hunter: technology that ensures super-high quality images in low-light environments
- Crowd flow counting, crowd density monitoring
- SIP (Smart Intrusion Prevention): combines artificial intelligence algorithms with real-time video analysis to accurately identify human and vehicular intrusions, minimizing false alarms caused by animal movements or weather conditions
- UMD (Ultra Motion Detection): thanks to its advanced AI algorithm, UMD is able to detect changes in the environment extremely efficiently, even in conditions of high speed or motion difficult to capture by other technologies
- WDR 120 dB
- Built-in microphone
- Audio 1 Input / 1 Output
- Alarm 1 Input / 1 Output
- Slot for microSD up to 256 GB
- PoE
- IP67
- IK10
- Metallic
- Corridor mode
- ONVIF Compatible
Specifications
| Brand | Uniview |
| Range | Prime |
| Image sensor | 1/2.8” Progressive Scan CMOS |
| Maximum resolution | 5 Megapixel (2880x1620) |
| Main Stream rate | 5MP (2880x1620), Max 60fps |
| Range performance | 63(D) 25(O) 12(R) 6(I) |
| Compression | Ultra265/H.265/H.264 |
| Lens | 2.8 mm |
| FOV | Horizontal: 106.7º Vertical: 57.7º Diagonal: 115.7º |
| Range performance | Detect: 63 m Observe: 25.2 m Recognize: 12.6 m Identify: 6.3 m" |
| Minimum illumination | 0.003 Lux (F1.6, AGC ON) 0 Lux with IR ON |
| Infrared range | 80 m |
| Image improvements | WDR (120dB), BLC, HLC, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR |
| SIP (Smart Intrusion Prevention) | Line crossing, Intrusion detection (based on human body, vehicle and two-wheeled vehicle detection) |
| Day / Night | Mechanical ICR filter |
| Internal memory | MicroSD card, Max 256 GB |
| Video Backup | ANR video recovery technology by installing a Micro SD card |
| Material | Graphene and metal |
| Audio | Integrated microphone |
| Network interface | Ethernet 10M/100M Base-TX |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Interoperability | ONVIF (Profile S/ Profile G/ Profile T), API ,SDK |
| Power | DC 12 V / 8 W, PoE IEEE802.3af |
| Temp. operation | -30º C ~ 60º C |
| Degree of protection | Weatherproof IP67, Anti-vandal IK10 |
| Dimensions | 74 (W) x 74 (H) x 206 (D) mm |
| Weight | 510 g |
In the box
- Uniview IP Camera
- Installation material
- User instructions
