UV-IPC2222SB-AHDF28KM-I1
Ga direct naar de productinformatie
UV-IPC2222SB-AHDF28KM-I1
- Uniview IP Bullet Camera - Prime range
- 2 MP | Lens 2.8 mm | microSD 512 GB
- IR 80 m | WDR 120 dB
- Light Hunter | 60 FPS
- PoE | UMD | SIP | IP67 | IK10
- Mic | Alarm | Audio
2 MP Prime Bullet IP camera with 2.8 mm fixed lens. It has Light Hunter technology that together with the real WDR of 120 dB and the possibility of capturing 60 frames per second, make its image quality superior. Additionally, it incorporates SIP and UMD to avoid false alarms.
- IP Bullet Camera - Prime Range
- 2 MP (1920x1080)@60FPS
- 2.8 mm fixed lens
- Minimum illumination 0.001 lux | 0 lux with IR
- IR range of 80 m
- Light Hunter: technology that ensures super-high quality images in low-light environments
- Crowd flow counting, crowd density monitoring
- SIP (Smart Intrusion Prevention): combines artificial intelligence algorithms with real-time video analysis to accurately identify human and vehicular intrusions, minimizing false alarms caused by animal movements or weather conditions
- UMD (Ultra Motion Detection): thanks to its advanced AI algorithm, UMD is able to detect changes in the environment extremely efficiently, even in conditions of high speed or motion difficult to capture by other technologies
- WDR 120 dB
- Built-in microphone
- Audio 1 Input / 1 Output
- Alarm 1 Input / 1 Output
- Slot for microSD up to 512 GB
- PoE
- IP67
- IK10
- Metallic
- Corridor mode
- ONVIF Compatible
Specifications
| Brand | Uniview |
| Range | Prime |
| Image sensor | 1/2.8” Progressive Scan CMOS |
| Maximum resolution | 2 Megapixel (1920x1080) |
| Main Stream rate | 1080P (1920x1080),Max 60fps |
| Compression | Ultra265/H.265/H.264 |
| Lens | 2.8 mm |
| FOV | Horizontal: 105.9º Vertical: 56.4º Diagonal; 137.7 |
| Range performance | Detect: 43.4 m Observe: 17.4 m Recognize: 8.7 m Identify: 4.3 m |
| Minimum illumination | 0.001 Lux (F1.6, AGC ON) 0 Lux IR ON |
| Infrared range | 80 m |
| Image improvements | WDR (120dB), BLC, HLC, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR |
| SIP (Smart Intrusion Prevention) | Line Crossing, Intrusion Detection (based on human body and vehicle detection) |
| Day / Night | Mechanical ICR filter |
| Internal memory | MicroSD card, Max 512 GB |
| Video Backup | ANR video recovery technology by installing a Micro SD card |
| Material | Metallic |
| Audio | 1 Input / 1 Output Integrated microphone |
| Alarm | 1 Input / 1 Output |
| Network interface | Ethernet 10M/100M Base-TX |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Interoperability | ONVIF (Profile S/ Profile G/ Profile T), API ,SDK |
| Power | DC 12V / 8W PoE IEEE802.3af |
| Temp. operation | -30º C ~ 60º C |
| Degree of protection | Weatherproof IP67 Vandal proof IK10 Overvoltage 6KVA |
| Dimensions | 245(D) x 86(W) x 86(An)mm |
| Weight | 820 g |
| UMD (Ultra Motion Detection) | Support Advanced motion detection, triggered only by detection of human skin and/or vehicle. |
In the box
- Uniview IP Camera
- Installation material
- User instructions
