UV-IPC2124LB-ADF28KM-H
- Uniview IP Bullet Camera - Easy range
- 4 MP | Lens 2.8 mm | microSD 128 GB
- IR 30 m | WDR 120 dB
- PoE | UMD | IP67
- Microphone
Easy Bullet type 4 MP IP camera with 2.8 mm fixed lens. Integrates analytics with SIP and UMD to reduce false alerts and also facilitates recording searches.
- IP Camera - Easy Range
- 4 MP(2688x1520)
- 2.8 mm Lens
- Minimum illumination 0.01 lux | 0 lux with IR
- IR range of 30 m
- UMD (Ultra Motion Detection): thanks to its advanced AI algorithm, UMD is able to detect changes in the environment extremely efficiently, even in conditions of high speed or motion difficult to capture by other technologies
- WDR 120dB
- Integrated microphone
- Slot for MicroSD card up to 128 GB
- PoE
- IP67
- Graphene and metal
- ONVIF Compatible
Specifications
| Brand | Uniview |
| Range | EasyBasic |
| Image sensor | 1/2.9” Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2560x1440) |
| Main Stream rate | 4MP (2560x1440)@25fps; 3MP (2304x1296)@30fps; 1080P (1920x1080)@30fps; 720P (1280x720)@30fps |
| Range performance | Detect: 63 m Observe: 25.2 m Recognize: 12.6 m Identify: 6.3 m |
| Compression | Ultra265/H.265/H.264/U-code |
| Lens | 2.8 mm |
| Minimum illumination | 0.01 Lux (Colour) |
| Infrared range | 30 m |
| Image improvements | WDR (120dB), BLC, HLC, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR |
| UMD | Ultra Motion Detection: Advanced motion detection with human and vehicle classification |
| Intelligent functions | Line Crossing, Intrusion (based on human body detection), Motion Detection, Audio Detection, Tamper Protection, Corridor Mode |
| Day / Night | Mechanical ICR filter |
| Internal memory | MicroSD card, Max 128 GB |
| Video Backup | ANR video recovery technology by installing a Micro SD card |
| Material | Graphene and metal |
| Audio | Integrated microphone |
| Network interface | Ethernet 10M/100M Base-TX |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Interoperability | ONVIF (Profile S/ Profile G/ Profile T), API ,SDK |
| Power | DC 12V / 5.5W PoE IEEE802.3af |
| Temp. operation | -30º C ~ 60º C |
| Degree of protection | Weatherproof IP67 Overvoltage protection 4 KV |
| Dimensions | 166 (D) x 63(Al) x 62(An) mm |
| Weight | 390 g |
In the box
- Uniview IP Camera
- Installation material
- User instructions
