UV-IPC2122SB-ADF28KM-I0
- Uniview IP Bullet Camera - Prime range
- 2 MP | Lens 2.8 mm | microSD 512 GB
- IR 40 m | WDR 120 dB
- Light Hunter | Counting
- PoE | UMD | SIP | IP67
- Reset button : Built-in microphone
2 MP Bullet IP camera with 2.8 mm fixed lens. Thanks to its Light Hunter technology and the fact that it has a real WDR of 120dB you can obtain clear images in difficult lighting conditions. Features SIP and UMD to avoid false alarms in video analytics.
- IP Bullet Camera - Prime Range
- 2 MP (1920x1080)
- 2.8 mm fixed lens
- Minimum illumination 0.001 lux | 0 lux with IR | IR Range 40 m | Light Hunter: technology that ensures super-high quality images in low-light environments
- Crowd flow counting, crowd density monitoring
- SIP (Smart Intrusion Prevention): combines artificial intelligence algorithms with real-time video analysis to accurately identify human and vehicular intrusions, minimizing false alarms caused by animal movements or weather conditions
- UMD (Ultra Motion Detection): thanks to its advanced AI algorithm, UMD is able to detect changes in the environment extremely efficiently, even in conditions of high speed or motion difficult to capture by other technologies
- WDR 120 dB
- Built-in microphone
- Slot for microSD up to 512 GB
- PoE
- IP67
- Metallic
- Reset button
- Corridor mode
- ONVIF Compatible
Specifications
| Brand | Uniview |
| Range | Prime |
| Image sensor | 1/2.8” Progressive Scan CMOS |
| Maximum resolution | 2 Megapixel (1920x1080) |
| Lens | 2.8 mm (H: 106.7º, V: 57.1º, D: 115.7º) |
| Range performance | 43.4 (D), 17.4 (O), 8.7 (R), 4.3 (I) |
| Main Stream rate | Endpoint request timed out |
| Extra Stream rate | 720P (1280x720)@30fps; D1 (720x576)@30fps; 640x360@30fps |
| Compression | Ultra 265, H.265, H.264, MJPEG |
| Minimum illumination | Colour: 0.001 lux (F1.6, AGC ON) 0 lux with IR on |
| Infrared range | 40 m |
| Image improvements | WDR (120dB), BLC, HLC, AGC, 2D/3D-NR, ROI, Privacy Mask, Smart IR |
| UMD | Yes (Advanced motion detection with human and vehicle classification) |
| SIP (Smart Intrusion Prevention) | Supports false alarm filtering: cross-line detection, intrusion detection, entry area detection, exit area detection |
| Statistical analysis | People flow counting and crowd density monitoring |
| Day / Night | Mechanical ICR filter |
| Internal memory | MicroSD card, Max 256 GB |
| Video Backup | ANR video recovery technology by installing a Micro SD card |
| Audio | Built-in microphone |
| Network interface | Ethernet 10/100 BaseT |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Interoperability | ONVIF |
| Power | DC 12V / 6W PoE IEEE802.3af |
| Temp. operation | -30º C ~ 60º C |
| Degree of protection | Weatherproof IP67 Surge protection |
| Dimensions | 155.9 (D) x 62.7 (H) x 63.1 (W) mm |
| Weight | 420 g |
In the box
- Uniview IP Camera
- Installation material
- User instructions
