UV-ADU8712-E-V3
Ga direct naar de productinformatie
UV-ADU8712-E-V3
- Uniview Decoder
- 12 HDMI output channels
- Max resolution 12 Mp
- Decode capability of 16*12Mpx (20fps)
- ONVIF Compatible
- Uniview
- IP Decoder
- Easy range
- 12 HDMI outputs up to 4K
- 4 HDMI inputs up to 4K
- Decoding capacity up to 16 x 12 MP
- H.265
- 2 ports RJ45 10/100/1000M
- 2 USB ports 3.0
- Audio I/O 2/2
- I/O alarms 4/4
Specifications
| Brand | Uniview |
| Output channels | 16 HDMI channels |
| IP compatible cameras | ONVIF |
| Bidirectional audio | 2 input / 2 outputs |
| Video inputs | 4 HDMI channels |
| Video stream format | H.265/ H.264 / MPEG4 |
| Split Screen | 1/2/3/4/5/6/7/8/9/10/13/16/36 |
| External Backup | 2*USB3.0 |
| Decoding capacity | 16*12Mp@20 / 16*4K@30 / 64*1080P@30 / 144*720P@30 |
| Alarms | 4/4 |
| Communication | RS485 / RS232 |
| Network Interface | 2 x RJ45 10/100/1000M |
| Power | AC 100~240 V, 50/60 Hz - 50W |
| Dimensions / Weight | 440 (H) x 339 (W) x 44 (D) mm |
| Weight | 3.95 Kg |
In the box
- Uniview Decoder
- Earth cable
- Power supply cable
