TK-TSW210
- Teltonika Industrial Unmanaged Switch
- 8 Ethernet RJ45 Gigabit +2 SFP Gigabit ports
- Ruggedized Aluminum Housing
- Plug and Play
- DC power 7 to 57V
- Status LED
- Teltonika
- Industrial Unmanaged Switch
- 8 Ethernet RJ45 Gigabit ports
- 2 SFP Gigabit ports
- Plug and Play
- DC power connector of 2 industrial power supply pins
- DC 7 to 57V
- Status LEDs
- Rugerized
Specifications
| Brand | Teltonika |
| Device | Industrial Unmanaged Switch |
| Ethernet | 8 Ethernet ports RJ45 10/100/1000Mbps |
| IEEE standards compliance 802.3 | 802.3i, 802.3u, 802.3x, 802.3az |
| Switching capability (non-blocking) | 20Gbps |
| MAC Table | 2K inputs |
| Packet Buffer | 128 Kb |
| Jumbo Frame | 9216 bytes |
| Technology | Auto MDI/MDI-X Cable detection |
| Power | DC connector 2 Industrial pins 7 to 57v |
| Power consumption | Standby: 1,03W / Max: 3,71W |
| Material | Aluminium |
| Degree of protection | IP30 |
| Temp. operation | -40º C ~ +75º C |
| Operating humidity | 10 ~ 90 % (non-condensing) |
| Optional Mounting Kit (Not included) | Rail Mounting Kit, Compact Rail Mounting Kit, Surface Mounting Kit |
| Dimensions | 44,2 (Al) x 132 (W) × 95.1 (D) mm |
| Weight | 500 g |
In the box
- Industrial Switch
- User instructions
