TK-RUTM56
TK-RUTM56
- Router Industrial Dual Modem: 1x 5G and 1x 4G Cat 4
- Ultra-fast connectivity up to 5G Gbps
- Complete resilience with a physical SIM and eSIM support
- Wi-Fi 5 Dual-Band Wave 2 up to 867 Mbps
- 5 Gigabit Ethernet ports for high-speed connectivity
- Automatic failover and WAN load balancing
The RUTM56 is a state-of-the-art industrial router that stands out for its unique dual-modem architecture, combining the power of the 5G Sub-6 GHz modem with a dedicated 4G LTE Cat 4 to ensure unmatched operational continuity. This configuration enables download speeds of up to 3.4 Gbps and provides true physical redundancy between two separate mobile networks, making it the ultimate solution for mission-critical applications in smart cities and industrial automation.
Based on the RutOS operating system, this device features an industrial security suite with multiple VPN protocols, an advanced firewall, and support for IIoT protocols such as OPC UA and Modbus. Its hardware is designed for performance, featuring a dual-core processor and an anodized aluminum chassis IP30 that withstands extreme temperatures, while the inclusion of an eSIM facilitates rapid global deployments.
Remote Management (RMS): Compatible with Teltonika RMS for centralized and secure fleet management from anywhere. It enables real-time monitoring, remote access (RMS Connect), and bulk updates, reducing operating costs by eliminating the need for on-site visits.
- Industrial Router 5G and 4G LTE Dual Modem
- Speed 5G: 3.4 Gbps DL / 900 Mbps UL
- 5 Ports RJ45 Gigabit Ethernet 10/100/1000
- Wi-Fi 5 Wave 2 Dual-Band MU-MIMO
- eSIM support and 2 physical SIM slots
- Dual-core processor 880 MHz MIPS1004Kc
- RAM: 256 MB and Flash: 272 MB
- GNSS positioning: GPS, GLONASS, and more
- Industrial voltage range from 9 to 50 VDC
- Ruggedized anodized aluminum chassis IP30
Specifications
| Brand | Teltonika |
| Type of equipment | Dual-Modem Industrial Cellular Router |
| 1 (5G) modem | 5G Sub-6 GHz (SA/NSA) (3.4 Gbps (DL) / 900 Mbps (UL) |
| 2 (4G) modem | 4G LTE Cat 4 (150 Mbps DL / 50 Mbps UL) |
| Bands 5G | n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n71, n75, n76, n77, n78 |
| SIM | 2 x Mini SIM slots (2FF) + 1 x eSIM profiles) |
| Wi-Fi | 802.11ac Wave 2 (Wi-Fi 5) Dual Band MU-MIMO |
| Wi-Fi rate | Up to 867 Mbps; Supports 150 simultaneous users |
| Ethernet | 5 x RJ45 10/100/1000 Mbps (1 WAN, 4 LAN) |
| CPU | MediaTek, Dual-Core, 880 MHz, MIPS1004Kc |
| RAM | 256 MB, DDR3 |
| Flash | 16 MB serial NOR flash + 256 MB serial NAND flash |
| Digital I/O | 1 x Input + 1 x Output (Open collector) |
| GNSS | GPS, GLONASS, BeiDou, Galileo, QZSS |
| VPN | OpenVPN, IPsec, GRE, WireGuard, ZeroTier, Tailscale, DMVPN |
| Security | SPI Firewall, DDoS Prevention, VLAN, TPM 2.0, Web Filter |
| Network Protocols | TCP, UDP, IPv4/v6, HTTP/S, MQTT, SNMP, BGP, OSPF, VXLAN |
| IIoT Protocols | OPC UA, Modbus TCP, DNP3, DLMS/COSEM |
| Management | Web UI, CLI, SSH, SMS, TR-069, MQTT, SNMP, RMS |
| Power | 9 - 50 VDC; supports passive PoE via LAN1 |
| Energy Consumption | Rest: < 4.5 W, Maximum: < 12.5 W |
| Housing Material | Anodized aluminum |
| Protection | IP30 |
| Temp. Job | -40 °C to +75 °C |
| Dimensions | 132 x 44.2 x 95 mm |
| Weight | 515 g |
In the box
- 1x Router Industrial RUTM56
- 1x Power supply for 24W
- 6x SMA magnetic mobile antennas
- 2x SMA magnetic dual-band Wi-Fi antennas
- 1x SMA adhesive GNSS antenna with a 3m cable
- 1x Ethernet cable, 1.5 m long
- 1x SIM adapter kit and Quick Start Guide
